Wenzhou Yika Porcelain Fuses High Voltage Fuse 12KV Fuse Holder DIN

FOB Price

US$ 10 - 80 / Piece

10 Pieces(Min. Order)

Port NINGBO SHANGHAI
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China	Brand Name	YIKA
Model Number	XRNT-12	Usage	High Voltage
Breaking Capacity	High	Safety Standards	Other, DIN

Packaging Details

Carton for FCL shipment / pallet for LCL shipment

Product Description

Porcelain Fuses High Voltage Fuse 12KV Fuse Holder DIN

Specifications

The XRNT Fuses can be used inindoor system of 50HZ and rated voltage of 3.6KV,7.2Kv,12KV,24KV,40.5KV:Used together with other switch facilities such as loading swithes,vacuum contactors,it can protect electric transformers and other electric facilities against overloading or circuit break.It is also a necessary accessory for high-voltage switch box,circular circuitcabinet,high Low voltage top-loading transformer substation.

Basic parameters

Type	Counterpart	Rated voltage	Rated current of the fuse (A)	Rated current of the fuselink (A)
XRNT-12	SDLAJ	12	40	3.15,6.3,10,16,20,25,31.5,40
XRNT-12	SFLAJ	12	100	50,63,71,80,100 ,(125)
XRNT-12	SKLAJ	12	125	125,160,200,250
XRNT-24		24	200	3.15,6.3,10,16,20,25,31.5,40 50,63,80,100 ,125,160,200
XRNT-40.5		40.5	125	3.15,6.3,10,16,20,25,31.5,40 50,63,80,100,125

Packaging

Company Profile

Wenzhou Yika Electric Co., Ltd.

Wenzhou Yika Electric Co.,Ltd. is a manufacturer of Fuse Cutout, Lightning Arrester, Insulator, Disconnector Switch, Circuit Breaker, Ring Main Unit etc. with well-equipped testing facilities and strong technical force. With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in Electricity Distribution System and Substation and other industries. Our products are widely recognized and trusted by users and can meet continuously changing economic and social needs. We welcome new and old customers from all walks of life to contact us for future business relationships and mutual success!
