Wenzhou Yika Ceramic Surge Arrester 10KV Porcelain Arresters Arrester Lightning
- NINGBO SHANGHAI
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Wenzhou Yika 66KV Substation Lightning Arrester Polymer Housing
-
Wenzhou Yika Gapless Composite 5KA Surge Arresters 11KV Lightning Arrester Electric
-
Wenzhou Yika 33 KV Lightning Arresters 10KA Polymer Surge Arrester Gapless
-
Wenzhou Yika Polymer Lightning Arrestors Lightning Arrester 5KA 33KV Surge Arrester
-
Wenzhou Yika High Voltage Arrester 110KV Surge Arrester Porcelain
-
Wenzhou Yika Types of Surge Arrester Polymeric Lightning Arrester 24KV
Product Details
| Place of Origin | Zhejiang, China | Brand Name | YIKA | |
| Model Number | Y5W-10, Y10W-10 |
Carton for FCL shipment / pallet for LCL shipment
Product Description
Ceramic Surge Arrester 10KV Porcelain Arresters Arrester Lightning
Normal operating conditions for Surge Arrester:
1. The ambient air temperature is no higher than +40°C, no lower than -40 °C .
2. The altitude above sea level does not exceed 1000m. ( the plateau area should be indicated when order.)
3. AC system frequency is 50Hz or 60Hz.
4. Power frequency voltage brought to bear on arrester for a long time does not exceed the continuous operation voltage of the arrester.
5. Maximum wind speed does not exceed 35m/s.
6. Te earthquake intensity does not exceed 7 degrees.
7. The pollution area should be indicated.
Gapless Arrester Electrical Parameter | |||||||
Type | Rated Voltage | MCOV | Max.Residual Viltage | 2ms square wave impulse withstand current | High current impulse withstand 4/10μs | ||
Steep current impuise1/4μS | Switching current lmpulse30/60μs | Nominal current lmpulse 8/20μs | |||||
kV | kV | kV | kV | kV | A | kV | |
Y5W-10 | 10 | 8.30 | 36.0 | 27.0 | 30.0 | 100 | 65 |
Y10W-10 | 10 | 8.30 | 36.0 | 27.0 | 30.0 | 250 | 100 |
Company Profile
Wenzhou Yika Electric Co.,Ltd. is a manufacturer of Fuse Cutout, Lightning Arrester, Insulator, Disconnector Switch, Circuit Breaker, Ring Main Unit etc. with well-equipped testing facilities and strong technical force. With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in Electricity Distribution System and Substation and other industries. Our products are widely recognized and trusted by users and can meet continuously changing economic and social needs. We welcome new and old customers from all walks of life to contact us for future business relationships and mutual success!
