Wenzhou Yika IEC 66KV Tension Insulator Polymer Insulators 66KV Insulator
- NINGBO SHANGHAI
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Wenzhou Yika IEC 24KV Polymeric Post Insulator / Support Insulator
-
Yika IEC Insulator 33KV Tension Composite Polymer Insulator Manufacturer
-
Wenzhou Yika IEC 110KV Composite High Tension Insulators Polymer Insulator Electrical Product
-
Wenzhou Yika IEC 220KV Polymer Insulator 220KV Composite Insulators
-
Wenzhou Yika IEC FXBU 24/70 High Tension Composite Suspension Insulator Types Insulators
-
Wenzhou Yika IEC Silicone Pin Insulator Pin Post Polymer Insulator 24KV
Product Details
| Place of Origin | Zhejiang, China | Brand Name | YIKA | |
| Model Number | FXBW-66/70, FXBW-66/100 | Type | Insulator | |
| Material | Composite Polymer | Application | High Voltage | |
| Rated Voltage | 66KV | Tensile Strength | 70KN, 100KN |
Carton for FCL shipment / pallet for LCL shipment
Product Description
66KV Tension Insulator Polymer Insulators 66KV Insulator
The Composite Insulator are made of glassfiber epoxy core rod, silicone rubber shed and metal fittings.
The silicon rubber shed adopt the whole packing pressure technique, and then to solve the key problem – interface electric spark puncture, which would affect the reliability of composite insulator.
Connection of the glassfiber rod and metal fittings, adopts the pressure welding technique of the international advanced level, and have the full automatic sound wave detection of defects system, high intension, beautiful outline, small volume, light weight, and the metal fitting of galvanization can corrosion prevention and exchange used with porcelain insulator.
This product is reliable structure, can’t damage the core rod, and take full advantage of the mechanical strength.
The dimension can be customized as per client's requirement.
| Technical Specifications: | |||||||
| Model | Rated Voltage | Rated mechanical load | Structure height | Min. Arc distance | Min. Creepage distance | Lightning impulse withstand voltage | 1 min P.F. withstand voltage (wet) |
| FXBW-66/70 | 66 | 70 | 920 | 700 | 1900 | 410 | 185 |
| FXBW-66/100 | 66 | 100 | 940 | 700 | 1900 | 410 | 185 |
Company Profile
Wenzhou Yika Electric Co.,Ltd. is a manufacturer of Fuse Cutout, Lightning Arrester, Insulator, Disconnector Switch, Circuit Breaker, Ring Main Unit etc. with well-equipped testing facilities and strong technical force. With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in Electricity Distribution System and Substation and other industries. Our products are widely recognized and trusted by users and can meet continuously changing economic and social needs. We welcome new and old customers from all walks of life to contact us for future business relationships and mutual success!
