Water Cooled Generator 25kva Powered by Yuchai Engine (excellent Chinese Brand)
- Qingdao Port Of China
- T/T
You May Like
-
30kva Yuchai Diesel Generator Price for Sale
-
3 Phase 30kva Diesel Generator With Yuchai Engine
-
Yuchai 30kva Diesel Generator Silent With 30kva Generator Head
-
Backup Use/continous Work Use Yuchai 30kw Two Cylinder Diesel Generator
-
Diesel Generador 30kw Powered by Yuchai Engine
-
China Reliable Weichai 20kw Electric Generator
Product Details
| Place of Origin | Shandong, China | Brand Name | Yuchai | |
| Model Number | HQ20GF | Output Type | AC Three Phase | |
| Speed | 1500RPM | Frequency | 50HZ | |
| Rated Power | 25kva | Rated Voltage | 230/400 | |
| Rated Current | 36A |
Product Description
water cooled generator 25kva powered by Yuchai engine (excellent chinese brand)
HQ28: prime 20kw/25kva 50Hz 1500rpm
Generator set | Genset Model | HQ28GF |
Rating Power (KW/KVA) | 20/25 | |
Standby Power(KW/KVA) | 22/27.5 | |
rating Ammeter(A) | 36.1 | |
Diesel Engine | Engine Model (Yuchai) | YC2115D |
Prime Power(KW) | 27 | |
Standby Power(KW) | 30 | |
number of Cylinder & Configuration | 2L | |
Displacement(l) | 2.493 | |
Compression Ratio | 16:01 | |
Aspiration Type | Natural | |
Combustion air Volume(m³/min) | 1.6 | |
Exhaust Gas Flow(m³/min) | 1.64 | |
Max. Exhaust Gas Temperature(°C) | 500 | |
Cooling Type | Water Cooled with radiator & fan | |
Max. permissible water temp.(°C) | 100 | |
Total oil capacity(l) | 8.2 | |
Rating Fuel Consumption(l/h) | 6.2 | |
Alternator | Rating Voltage(V) | 400/230 |
Alternator Model | MAG180-20-4S | |
Rating Capacity(KW/KVA) | 20/25 | |
Power Factor | 0.8 | |
Exciting type | Self-Exciter | |
Voltage regulation | AVR | |
No. of Phase | 4 | |
Protection Class | IP21 | |
Class of Insulation | H | |
Battery | Rating Capacity(AH) | 60 |
Dimension | Generator set dimension LXWXH)(mm) | 1300X750X1100 |
Weight | Weight (kg) | 600 |
Performance Feature
Engine and alternator shall be mounted on a same frame steel skid.
Built-in damper for anti-vibration.
Small size, low weight, easy to operating, installation and maintenance.
World most famous brand diesel engine: Yuchai 25kva
Famous brand AC alternator: Marathon/ Stamford/Leroy Somer/Shanghai MVC
Advanced and reliable control module: Key start, Auto start, Remote control by PC with RS232/485
Full range protect function and alarm shutdown feature.
Alternator Feature
Brush-less, 4 poles, rotation magnet.
IP21-23 (NEMA1) enclosure is standard for all industrial alternators.
The insulation system is Class H
Simple installation and maintenance, with easy access to terminals, rotating diodes
Wide range of flange adaptors and single bearing disc coupling.
Standard 2/3 pitch windings avoid excessive neutral currents
AVR auto voltage regulator, auto exciter, auto adjustment
Standard Accessory
Common steel base frame, Damper, Exhaust silencer, Flexible pipe, Battery and connecting wires, Operation manual and document.
Optional Accessory
Engine coolant and oil heater, Alternator space heater, Cooling for heat exchanger, Control system with RS232/485 communication interface, Battery charger by main supply, Fuel-water separator, Daily fuel tank, ATS & paralleling system, and Moving Trailer.
