Automatic Generator With ATS And AMF 30kva ~300kva Diesel Generator Price

FOB Price

US$ 2,250 - 9,900 / Set

1 Set(Min. Order)

Port Qingdao Port of China
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China	Brand Name	Huaquan
Model Number	HQ	Output Type	AC Three Phase
Speed	1500/1800	Frequency	50/60HZ
Rated Power	30KVA~300KVA	Rated Voltage	230/400V
Rated Current	54A-540A

Product Description

Automatic generator with ATS And AMF 30kva ~300kva diesel generator price

Product Description

Generators Diesel Standard Configurations
1	Standard High-level quality engine Cummins series
2	Standard High-level quality alternator, Stanford, Brushless, 100% copper wires. Protection Grade: IP23, Insulation Class H.
3	No-maintenance start battery
4	After acidification under frame, High-level strong
5	Electric start, use key start
6	Standard control panel Spray-print or LCD show panel
7	Daily fuel tank
8	High-level shock absorber system
9	Ripple flexes exhaust pipe, exhaust siphons, flange, Muffler
10	40°C radiator as standard
11	Exhaust silencer
12	Charger motor for battery.
13	Standard export box
14	Manuals
15	Tools box

Product Picture Show

Product Details

Genset Model	Diesel Generator		Diesel Engine		Alternator		Overall Size (mm)	Gross Weight (kg)
Genset Model	Prime Power (KW/KVA)	Standby Power (KW/KVA)	Model	Rated Power (KW)	Model	Rated Power (KW/KVA)	Overall Size (mm)	Gross Weight (kg)
HQ9GF	9/11	10/12	2100D	15	SWT-8.8	9/11	1550×620×960	660
HQ15GF	11/14	12/15	2100D	15	SWT-10.8	11/14	1550×620×960	660
HQ13GF	13/16	14/18	2100D	15	SWT-12.8	13/16	1550×620×960	660
HQ18GF	18/23	20/25	K4100D	30.1	SWT-18	18/23	1600×640×1000	680
HQ22GF	22/23	24/31	K4100D	30.1	SWT-22	22/23	1600×640×1000	680
HQ25GF	25/31	28/35	K4100D	30.1	SWT-25	25/31	1600×640×1000	680
HQ30GF	30/38	33/42	K4100ZD	40	SWT-30	30/38	1700×700×1100	790
HQ34GF	34/43	38/47	K4100ZD	40	SWT-34	34/43	1700×700×1100	810
HQ40GF	40/50	44/55	K4100ZD	40	SWT-40	40/50	1700×700×1100	860
HQ50GF	50/62.5	55/68.75	R4105ZD	56	SWT-50	50/62.5	1870×720×1250	860
HQ60GF	60/75	66/82.5	R6105ZD	84	SWT-60	60/75	2210×720×1380	910
HQ75GF	75/94	75/94	R6105ZD	84	SWT-75	75/94	2210×720×1380	910
HQ80GF	80/100	88/110	R6105AZLD	110	SWT-80	80/100	2300×720×1550	1030
HQ90GF	90/112.5	99/124	R6105AZLD	110	SWT-90	99/124	2300×720×1550	1300
HQ100GF	100/125	110/138	R6105AZLD	110	SWT-100	110/138	2340×720×1550	1350
HQ120GF	120/150	132/165	R6105IZLD	132	SWT-120	120/150	2550×740×1550	1400
HQ150GF	150/187.5	165/206	R6105IZLD	156	SWT-150	150/187.5	2570×775×1725	2200
HQ184GF	184/230	202.4/253	6126ZLD	226	SWT-184	184/230	2800×800×1800	2900
HQ200GF	200/250	220/275	6126ZLD	226	SWT-200	200/250	2800×800×1800	3000
HQ250GF	250/312.5	275/343	6126IZLD	330	SWT-250	250/312.5	3000×850×1800	3200
HQ300GF	300/375	330/412.5	6126IZLD	330	SWT-300	300/375	3000×850×1800	3500

Our Engine Features

Diesel Gengine----Ricardo

Ricardo diesel generators, adopting diesel engines as power, which are manufactured by the company introducing British Ricardo technology, bear the features of compact structure, convenient operation, stable operation, low fuel consumption, low emission and low noise. Each performance indicator has reached National standard JB/T8981-1999, also meeting international standard IEC34-1. The product is widely used in numerous industries, including highways, telecommunications, hospitals, securities companies, high-rise buildings, public security, transportation systems, television station and etc.

Features of Ricardo diesel generator sets:

1. Ricardo diesel generators have good power performance, economic and sound reliability, emission reaching Euro II standard
2. Ricardo diesel generators adopt vertical four-cylinder, six-cylinder, water-cooled, four stroke, direct injection high-speed diesel engine.
3. Ricardo diesel generators have passed IS09001 quality system certification.
