motocoltivatore chinese traktor diesel tractors

FOB Price

US$ 465 - 500 / Set

10 Sets(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Farm Cultivator
Power Type	Diesel	Power(W)	6300
Certification	ISO9001, CE	Warranty	1Year
Use	Rotary tillage	Place of Origin	Henan, China
Brand Name	Tennma	Model Number	1WG6.3(Big HP PD1)
Weight	135KG/297 lbs	Dimension(LWH)	17513580cm/68.8953.1531.5in
After-sales Service Provided	Engineers available to service machinery overseas

motocoltivatore chinese traktor diesel tractors

Main Parameter:

Model	1WG6.3(Big HP PD1)
Tiller	Rated Power		6.3kw
	Starting System		Recoiling
	Transmission		All Gear Driving
	Clutch		Oil immersed
	Gear shifting		0, 1
	Tyre size(in.)		350-5(diameter:18, width:5)
	Diameter of Cutters(in.)		11.8
	Speed of Cutters(rpm)		150rev/min 180rev/min
	Tilling Depth(in.)		≥ 10cm
	Tilling Width(in.)		135cm
	Efficiency (acre/h)		1.5
	Accessories		1 set of tri-group rotary blade included
Engine	Engine Series		Diesel 186F
	Engine Type		Single Cylinder Water-Cooling 4-stroke Horizontal
	Cylinder DIA*Stroke(in.)		3.4*2.8
	Compression Ratio		18:1
	Lubricating System		Direct injection
	Fuel Tank Capacity(L)		5.5
	Fuel Consumption(kg/kw.h)		0.3
	Spark plug gap(in.)		0.70-0.80mm
	Displacement(cc)		418cc
	Max. Torque(N.m/2500rpm)		11.0
	Cooling System		Water Cooling
	Max Power(kw/3600rpm)		6.3KW
Weight	Net/Gross Weight(kg)		135/140
Others	Package Dimension(LWH)		4033.435.4(in.)
	Packages		Carton Box/ Plywood Case
	Min. Order(sets)		10
	Port		Shanghai/Qingdao
	Delivery Time		2 Weeks
	Payment Terms		T/T,L/C
	Warranty Time		1 Years
	Loading QTY	20GP		50sets
		40GP		100sets
		40HQ		120sets

Machine Feature
