2016 New Smart Home Wireless Video Intercom Phone Control IP Door Phone Wifi Doorbell Camera Wireless Door bell

Model

Doorbell-01

Item

doorbell

Device Type

1.0 Megapixel CMOS sensor

Size

1/4

Day and Night

Yes

Min.Scene  Illumination

0lux(IR ON)

Infrared sensitivity

Support

Filter

IR-CUT

LENS

Lens

3.6 MM

Focus

Fixed Lens

Aperture

Fixed Aperture

Video

Compression

H.264

  Picture Resolution

Main Flow:   1280*720@20fps

Minor Flow:   640*360@30fps

Flow Type

Dual Stream encoding

Bit Rate

128-8192kbps

Bit Rate Type

CBR/VBR

S/N Ratio

>50DB

Image enhancement

Auto White Balance,Backlight compensation,Brightness,Contrast,Saturation adjusted

Subtitles input

Support channel name, date/time

Flip Config

Up/down, Left/right

Audio/ Alarm

equipment

Built-in MIC,horn

  Audio input/output

one channel audio input, one channel audio output

Audio  Compression

G.711

Alarm way

Motion Detection:Configure motion detection area,detecting sensitivity is adjustable

Cover alarm:The alarm sensitivity is adjustable

Alarm processing

The control center to monitor,Go to PTZ preset pos,Send E-mail, Log record

PIR

support

Network

Protocal

TCP,UDP,IP,HTTP,SMTP,DHCP,DNS,DDNS,ARP,ICMP,SMTP,POP3,NTP,RTP, RTCP,Pelco-D

Ethernet

Ethernet (10/100 Base-T),RJ-45 connector

Safety

IP address filtering,User level password protection,The user access log

Software

WEB Browser

Microsoft Internet Explorer 6.0 and above,google,firefox etc.

Software Management

CMS and the devices

Software intelligence function

Motion detection,Miss object detection, Moving object tracking, counting, Retrograde motion detection, etc.

Event action

Files are stored to the back end equipment,Send E-mail,Send SMS,Zoom in alarm,op ap map ,Go to PTZ preset pos etc

Mobile Phone

Support iPhone,Android

Remote Access

DDNS,Software,P2P

Features

The doorbell visiting log

Keys for hd video at the same time,Mobile phones can be synchronous log and video files, and mobile terminal playback.

Tamper design

support

Anti-theft design

Stay in 15 seconds to 30 seconds PIR automatically detects, automatically push the mobile phone screen

Physical properties

Accessories

Power adapter, Network cable, Stand, Operation manual, CD, Screw bag (default accessories)

Power Comsumption

DC 12/24V

Temperature

-10°C——60°C

Humidity

10%-80%

  Weight

KG

Dimension

mm L*W*H

Certification

CE,FCC
