X-09C Computer Controlled Tape Cutting Machine With Cold Knife

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Heavy-Duty Tape Cutting Machine X-09C
with cold knife
Cutting width: 180mm
new products

X-09C Computer controlled Tape Cutting Machine with cold knife

SPECIFICATIONS

MODEL	CUTTING LENGTH mm	Max. CUTTING WIDTH mm	CUTTING SPEED p/min	WEIGHT kg	VOLTAGE FREOUENCY V/Hz	POWER KW	Max. BLADE TEMP °C	CUTTING ANGLE	PACKAGE SIZE (L.W.H)mm	LOADING RATE PIC
X-09C	15-99999	180	120	95/75	110V/220V 50/60	1.4	-	-	550×440×450	1

Special features:

Compensation:It can recover the differences caused by the material flesibility dissimilarity.
Memory: It will save the current datas automatically before the machine is closed.
Decimal point:special decimal point function,raised the accuacy of the product consumedly.
Self-check:when a defect in the system,LD screen will display breakdown source automatically,in order to expel in the convenient check.
Automatic power failure: 1 hour after machine stopped working, the main driving system will break power supply automatically to promise the service life of machine.
Automatic pause: once the material uses up,will stop a current work automatically.
Automatically and neatly cut, easy operation.
High speed: It can cut 100~120 cut per minute. (50mm long)
Accuracy: Cut-length is accurate cwing to a stepping motor
Cutting type: Cutting is neat due to using a cold cutter which is durable.
Automatic operation: It works automatically only by setting length and quantity
Automatic stopper: It stops automatically if materials run out during operation.
Memory: Set-length, set-q'ty & set-speed are not erased even if power off & on.
Application:
Woven Tapes, Strip Tapes, Bag Band, etc. But no pure cotton materials
Suitable material: strip tapes, ribbon tape, bag band small webbing, etc.
