Factory Price Sand Making Machine,Sand Maker
- Qingdao Tianji Shanghai CHINA or Based on ur designation
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Condition | New | Type | Other, sand maker | |
| Application | Limestone,coal,gypsum,etc | Motor Type | AC Motor | |
| Power(W) | 380V or as your requirements | Capacity(t/h) | different | |
| Place of Origin | Henan, China | Brand Name | Xingbang | |
| Model Number | Different | Dimension(L*W*H) | Different | |
| Weight | Various | Certification | CE, CQC,ISO9001:2000, CE, CQC,ISO9001:2000 | |
| Warranty | 12 month | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Sand Making Machine,Sand Maker
Hot Sale!!! Factory Price!!!
Spare parts for free for the top five customers every month!!!
1.Advantages of Sand Making Machine,Sand Maker
1) Long service life
2) Simple structure and low investment cost
3) Working noise <75db, and little dust pollution
4) Less abrasion of impeller liner, convenient in maintenance
5) Cubic shaped finished products, high stack density, and low iron pollution
2.Application of Sand Making Machine,Sand Maker
Sand Making Machine,Sand Maker is widely used in fine crushing and rough grinding of metal, mineral, building aggregate, concrete, glass, and so on. Compared with other kind of crushers, it is more advanced in crushing intermediate hard, extra hard and abrasive material, such as gravel, quartz, sandstone, basalt, silicon carbide, diamond grain, and sintered bauxite, etc.
3. Structure of Sand Making Machine,Sand Maker
The design of Sand Making Machine,Sand Maker adopts unique rotor structure, wear proof material technology, optimized broken speed and the perfect hydraulic combination. It is a successful example of perfect combination of the specialized technology and finely machinery manufacturing, which also reflects the new technology and the new craft.
4.The Main Technical Parameter
| Model | VSI7611 | VSI8518 | VSI9526 | VSI1140 | |
| Throughput capacity (t/h) | Center and Ring feeding | 120~180 | 200~260 | 300~380 | 450~520 |
| Center feeding | 60~90 | 100~130 | 150~190 | 225~260 | |
| Max. Feed Size (mm) | Soft material | <35 | <40 | <45 | <50 |
| Hard material | <30 | <35 | <40 | <45 | |
| Rotation speed(r/min) | 1700~1890 | 1520~1690 | 1360~1510 | 1180~1310 | |
| Power of double motor (KW) | 110 | 180 | 264 | 400 | |
| Overall dimension L x W x H (mm) | 3700×2150×2100 | 4140×2280×2425 | 4560×2447×2778 | 5000×2700×3300 | |
| Weight (t) | 11.8 | 14.5 | 17.8 | 25.6 | |
| Power supply | 380v,50Hz | ||||
| Overall dimension L x W x H (mm) | Power for double motor | 2 x 0.31 KW | |||
| Safety | To make sure the supply of oil with double oil pump,working without oil, temperature when water cools, start the motor byheating it in winter. | ||||
| Power for oil box heater | 2 KW | ||||
| Overall dimension | 820x520x1270 | ||||
Kindly note: Please Inform us the follow figures:1).feeding material 2) Feeding material MAX. Size (mm)
3)Final mesh size (mm) 4)Capacity (t/h), and we can produce other specifications according to your demands.
5.Best Service for You
1)Pre-sale Service
According to your requirements, we offer you the proposal plan, flow chart, then design the required equipment.
2)Sale Service
Our company sends technicians to the production site for guiding the installation, adjustment, training the operators, and help you check the working of the equipments
3)After-sale Service
To set up the long term friendship, we will regularly revisit our customers and help solve the problems as possible as we can.
Spare parts for free for the top five customers every month !!!
About XBM
Henan Xingbang Heavy Machinery Co., Ltd. is a world leader in the manufacture and distribution of crushing, grinding, screening, washing and recycling, beneficiation, parts and so on, as well as sand stone aggregate production line used in quarry, mining and cement plant.It has over 20 years experience in this field.
Sand making machine,sand makers in the factory
We have professional R&D Team, and strict quality control is exercised in every step of the production process.
Safety of Products Loading and Delivery
Sand Making Machines Working Efficiently in Client Site
Exported to more than 30 countries in Africa, Asia, America
24 Hours Service Hotline
Welcome to visit our factory We are here waiting for you......
