Home > Products > New Products > 8" TH8 DTH hammer for water well drilling
8" TH8 DTH hammer for water well drilling
- 5000 Set / Sets per Month
- shanghai
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Hunan, China | Brand Name | teamwhole | |
| Model Number | 8"TH180 DTH hammer | Type | Other | |
| Machine Type | Drilling Tool | Certification | Other | |
| Material | Carbon Steel | Processing Type | Forging | |
| Use | Well Drilling |
Product Description
Specifications
1. mainly for water well2. reliable performance
3.long service life
4.high efficiency rate
5.good seal effect
Usage
It's used for all kinds of the fields,eg mining,tunnel,construction and especially for the water well drilling.
Specifications
1.For water well drilling
2.Simple structure and easy operation
3.Reliable performance
4.Good seal effect
5.Long service lif
Specification
1.Excellent for water well drilling.
2.Drill holes from 203-271
3.Hole depth more than 200 meters.
4.Use under 25 bar air pressure.
5.The air cousumption is about 1500cfm
Matched products
89mm drill rods with API 4 1/2"REG BOX
bits with COP84.DHD380,Mission80,QL80,SD8 shanks
Quality Gurrantee
Products with any problem caused by unqualified material and maching,will be replaced when providing photos of broken parts and products serial number
Parameter
Description |
Product Code | Bit Shank | Thread Connection |
Outer Dia. (mm) | Length Without Bit (mm) | Weight (kg) | Flat Wrench (mm) | Rec. Hole Size (mm) | ||
TH180 | 260000 | DHD380 COP84 | API 4 1/2" REG PIN | 180 | 1522 | 190 | 150 |
203-271 | ||
Working Pressure (bar) |
Impact Frequency at 17 bar (Hz) | Normal Axial Pressure (kN) | Rec. Rotation Speed (r/min) | Air Consumption (m³/min) | ||||||
14-24 | 20 | 18.3 | 30-40 | 12bar | 17bar | 24bar | ||||
| 22.5 | 28.2 | 39.6 | ||||||||
Hammers Matching To Other Bits | ||||||||
Description | Product Code | Bit Shank | Thread Connection | Outer Dia. (mm) | Length Without Bit (mm) | Weight (kg) | Flat Wrench (mm) | Rec. Hole Size (mm) |
TH180-QL80 | 260001 | QL80 | API 4 1/2" REG PIN | 180 | 1515 | 190 | 150 | 203-271 |
TH180-Mission80 | 260003 | Mission80 | 1515 | 188 | ||||
TH180-MACH80 | 260005 | MACH80 | 1522 | 190 | ||||
TH180-SD8 | 261000 | SD8 | 1492 | 195 | ||||
Working Pressure (bar) | Impact Frequency at 17 bar | Normal Axial Pressure (kN) |
Rec. Rotation Speed (r/min) | Air Consumption (m³/min) |
14-24 | 20 | 18.3 | 30-40 | 14bar 22.5 | 17bar 28.2 | 24bar 39.6 |
