NMO350 Nylon6 Monofilament filter mesh, nylon screen mesh

 Product Description

Nylon screen mesh

• Technical parameters

  Item	NO	JPP19
  material		Nylon6 Monofilament
  mesh count	Mesh/cm Mesh/inch	19
  		48
  yarn diameter	micron	180
  mesh opening	micron	350
  thickness	micron	335
  weight	gsm	125
  open area	%	43
  width	m	1.83



• Features

1.Even hole size,high precision of filtration

2.Smooth filament, immersion resistance,no material drop off

3.Stable chemical and physical properties

4.Widely used in liquid filtration,especially in making tea and coffe bags

• Certificates

1.Standard of quality:ISO9001:2008

2.Food approved:FDA,EC,NO SILLICON

3.Environmental certificate:ROHS

4.Material safety:MSDS,SVHC

5.Raw material test:PA66 MATERIAL TEST REPORT

• Finishing process

HTHP ultrasonic cleanling,high tempreture stabilized finish,unti-infiltration water treatment in 10000-grade purification workshop.

• Testing

a. Thread measuring

selecting the most suitable fibers for intended application

b. Check the mesh count

measuring the mesh count by pick glass

c. Check the mesh opening

measuring the mesh opening & thread diameter by microscope

d. One splice marked with red thread

• Package

Each roll packed in plastic bags,then in weaving bag or carton or woden case.It also can be customized

• Service

1.Heat cutting

2.Laser cutting

3.Ultrasonic welding

4.Raising

5.Calendaring

• Manufacturing process

•
  Company Information



  Expo

1.Nov. 15^th  2011- Nov. 17^th  2011 ,Filtration 2011held in Chicago,USA

2.Mar. 22^th  2011- Mar. 24^th  2011 ,FILTECH2011held in Wiesbaden,Germany
