Devilbiss Lincare Cpap Respironics for Heart Disease

Specifications

 PRODUCT'S NAME

     Devilbiss Lincare Cpap Respironics for Heart Disease 1.Overview

A continuous positive airway pressure (CPAP) machine is used mainly by patient for the treatment of sleep apnea at home. Obstructive sleep apnea occurs when the upper airway becomes narrow as the muscles relax naturally during sleep. This reduces oxygen in the blood and causes arousal from sleep. The CPAP machine stops this phenomenon by delivering a stream of compressed air via a hose to a nasal pillow, nose mask or full-face mask, splinting the airway(keeping it open under air pressure)so that unobstructed breathing becomes possible, reducing and/ or eliminating apneas and hypopneas. This has an additional benefit of reducing or elimination the extremely loud snoring that sometimes accompanies sleep apnea.

CPAP treatment can be highly effective in treatment of obstructive sleep apnea. For some patients, the improvement in the quality of sleep and quality of life due to CPAP treatment will be noticed after a single night’s use. Often, the patient’s sleep partner also benefits from markedly improved sleep quality, due to the amelioration of the patient’s loud snoring. It is the best way to help patients continue therapy by educating them on the health risks of sleep apnea and providing motivation and support.

a) Safety Introduction:(Please accept the belowed requirements to avoid to happen a accident)

1.The instrument is for indoor work,it should work in normal room temperature.

2To use the instrument by the doctor's advice, or only under the guidance of professionals.

3.To adjust the treatment pressure by the hospital’s doctors or licensed personnel.

4.The instrument used only for positive airway pressure, non-life support for critically ill patients.

5.Before using,to check your power strip,in condition of no damage,no leakage,then plug in, to ensure the safe use of electricity.

6When to transfer or to handle equipment, first turn off the power switch,then unplug the power plug.

7.To ensure fresh air indoors, not use in a hazardous gas environments.

8.If added the oxygen,to handle at the oxygen mask department.To prohibit to work in the intake of the instrument! To avoid burning.

9.After putting water into the humidifier, please do not flip the apparatus,to avoid water into the instrument to burn circuit. If do not use it for long-term,drain water from wet tank to prevent mildew.

10.Do not disassemble equipment chassis. .

b)Reliability Introduction

While the instrument works,if a power downs or a power lines is off, the instrument will alarm by beep, then, should turn off the power switch on back baord and check the cause,in case the power cord off,please re-plugged the power cord and then boot in order.

c) Travel with portable machine

The instrument is equipped with a special backpack for convenient travel, with 110v/230v manual conversion, can be adapted throughout the grid.

(d) Application Scope

This instrument applies to hospitals and family therapy obstructive sleep apnea syndrome.

e) Features

1.Enhanced digital temperature control, stable humidification effect,low body temperature .

2.Constant temperature and humidification in one, smaller volume, easy to carry.

3.Delaying step-up, comfortable sleep in condition of low pressure,.

4.With the power off alarm to ensure safety.

5.Low noise.

2.Main Specifications

1, Normal Working Conditions

Environmental temperature: 5 °C ~ 40 °C;

Relative Humidity: ≤ 80%;

Atmospheric pressure: 700hPa ~ 1060hPa;

1. Power Supply: AC voltage 110V ~ 230V ± 10%; Frequency 50Hz (or 60Hz).

2, The capacity of constant temperature wetting tank: 250mL.

3, Weight: 1.8kg.

4, Input power: 180VA.

5, The working system: continuously.

6, Security types: II class, type BF.

7, Fuse: 220V, 5A; Φ5mm × 20mm.

8, Pressure adjustment range: 4.0hPa ~ 20.0hPa ,adjustable interval 0.5hPa.

9, With 0 ~ 45min delaying step-up function, seting the interval 5min.

10,Humidication temperature is adjusted by 16 stalls,the temperature of the air outlet is less than 41 °C.

11, The machine noise: <45db.

12, Continuous working time: 8h-12h.
