Certified Irrigation system Sistema de riego waterwheel and circle irrigation machine

Certified Irrigation system Sistema de riego waterwheel and circle irrigation machine

Advantages

1. Advanced production facilities and perfect process to realize mass professional, high-quality, low-consumption and efficient mode of production.

2. All parts are hot dip galvanized and meet US ASTN-A123 Standard to assure 20 years free from corrosion.

3. Can cover 1.67-167ha. By one single center pivot.

4. Suitable for large-area irrigation of cash crops such as corm potatoes, beans, grains, pasture grass, cotton and fruit trees.

5. Highly professional technical person can supply installation overseas.

	Control cabinet Waterproof. Percentage timer for speed adjustment. Emergency stop. Low water pressure shut off. Lighting arrestor. Options: buttom type, touch screen type, the phone remote control type.
Center pivot Heavy duty cross members. Hot dip galvanized steel structures. Meet US ASTN-A123 Standard.
	Tower An exclusive double sided welded brace. Wide spread legs. Heavy duty drive tube. Irrigation Tire.
Spans V type bridge structure. Standard 11-gauge pipelines.  X type bracing. Forged steel ball and socket hitch.

Drivetrain

High strength steel worm and output shaft.

Each gearbox filled with extreme pressure/multi-purpose gear oil.

UV resistant dust seals.

Totally enclosed internal air expansion chamber.

Top oil fill provision.

Sprinklers

Customer can select the proper sprinkler package based on climate, soil type, crops, and topography.

Booster and End guns

End guns can add five to ten more irrigated acres (2 to 4 ha) in a standard quarter section. Booster pumps are available in either 130 GPM (8.2 LPS) or 200 GPM (12.6 LPS) sizes when additional pressure is required to increase end gun reach.

Real projects

 Weishi Huifa Machinery Plant is a manufacturer of irrigation system and saler for agricultural machinery. Located in Henan China, Founded 1999.

1, What informations are needed to make a best budget?
