glass fiber geogrid, fiberglass geogrid 30~200kn/m
- Qingdao
- T/T
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | ROAD or OEM | |
| Model Number | EGA50-50,EGA80-80,EGA100-100 | Material | Fiberglass |
Product Description
Specifications
1)glass fiber geogrid, fiberglass geogrid2)Materials:glass fiber
3)Tensile strength:MD/CD:30~200kn/m
4)WIdth:1~6m
Product Specification---Fiberglass Geogrid
1)fiberglass geogrid /glass fiber geogrid
2)Materials:fiberglass
3)Tensile strength:MD/CD:30~200kn/m
4)WIdth:1~6m
Introduction: Fiberglass geogrid is a kind of new favorable earthwork base material to strengthen the road surface and roadbed. This product is composed of fiberglass filaments that are coated with an inorganic sizing agent
Features:
1. High tensile strength in warp and across directions
2. Low Elongation
3. High flexibility
4. High and low temperature resistance
Application: This product is used to strengthen the soft land, such as railway, airport, irrigation work, and dyke, roadbed,and softland loading capacity strengthen.
Specification | EGA30-30 | EGA50-50 | EGA80-80 | EGA100-100 | EGA120-120 | EGA150-150 | EGA200-200 | EGA300-300 | |
Mesh size(mm) | 25.4×25.4 Or 12.5×12.5 Or 50.8x50.8 | ||||||||
Breaking strength ≥(KN/m) | Warp direction | 30 | 50 | 80 | 100 | 120 | 150 | 200 | 300 |
Across warp | 30 | 50 | 80 | 100 | 120 | 150 | 200 | 300 | |
Elongation at break ≤(%) | Warp direction | 4 | |||||||
Across warp | 4 | ||||||||
Elasticity modulus(GPA) | 67 | ||||||||
Thermal tolerance | -100~280°C | ||||||||
Width | 1~6m | ||||||||
