high strength geonet

FOB Price

US$ 0.9 - 1.2 / Square Meter

5000 Square Meters(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China		Brand Name	OEM
Model Number	CE121, CE131,CE151,

1)geonet
2)material: high-density polyethylene (HDPE) .
3)Spec:CE121,CE131,CE151
4)width:2m or 2.5m

The introduction and application of the geonet:

It is made of high-density polyethylene (HDPE) and the ultravioresistant agent with the property of aging resistance and erosion resistance.
Using the geo-net on the roadbed of the roadway and railway can distribute the load effectively, improve the loading capacity and the stability of the roadway, and prolong its service life.
Spreading the geo-net in the dyke protection in the reservoir and the river can protect it from the landslide.
And with the features of good flexibility and strong erosion resistance, using it in the coast engineering can amortize the concussion and the erosion of the surf

Spec and property indexes of geonet

Spec Item	CE121	CE131	CE151	DN1	HF10
Weight per sq.m.(g/m2)	730±35	630±30	550±25	750±35	1240±60
Mseh size(mm)	8±1X6±1	27±2X27±2	74±5X74±5	10±1×10±1	10±1×6±1
Net width(m)	2.0₀^+0.06or2.5₀^+0.06
Length of the reel(m)	50.0₀⁺¹or40.0₀⁺¹
Maximum drawing force≥(KN/m)	6.2	5.8	5.0	6.0	18
Remark	The special spec or size can be manufactured according to the demands of the contract or agreement
