Hot-dip Galvanized 11kv 33KV Electrical Power Cross Arm/Angle Steel for Pole Line Hardware
- tianjin
- T/T
You May Like
-
Brand Hot-Selling Hot-dip Galvanized 11kv 33KV Cross Arm/Angle Steel for Pole Line Hardware
-
Tension / Straight Galvanized Steel Cross Arm , Alley Arm Crossarm Brace/angle Steel
-
Best Quality Cross Arm/Channel Steel/ Angle Steel For Overhead Power Line Fitting
-
Famous Brand Hot Dip Galvanized Steel Angle Beam/Pole Arm/Cross Arm for Overhead Transmission Line Accessories
-
High Quality Cross Arm Included Angles and Channel, Made for Electric Power Fitting
-
High Quality Factory Supply Cross Arms and Galvanized Steel Angles
Product Details
| Place of Origin | Hebei, China | Brand Name | weichuang | |
| Model Number | 11kv 33kv |
Product Description
Hot-dip Galvanized 11kv 33KV Electrical Power Cross Arm/Angle steel for Pole Line Hardware
1.high strength and well durable
fessional manufacturer
3.Q235 steel material
4.Small order accepted
5.Prompt delivery
6.Accurate CAD in drawing
7.L/C,T/T,Western Union short Payment
Hot-dip Galvanized 11kv 33KV Electrical Power Cross Arm/Angle steel for Pole Line Hardware
1.Tensile Strength (N / square mm):375 N /mm2 up to 510 N/mm2
2.Yield Point (N / square mm):235 N/mm2
3.Zinc Coating Wt (gram / square meter):505 (up to clients' demands)
4.Zinc Coating Thickness ( microns ):70 (up to clients' demands)
Galvanized steel cross arm:
1.According to use can be divided into: linear cross arm; Angle of cross arm; Resistance to a cross arm.
2.According to the material can be divided into: iron cross arm; Porcelain crossarm; Synthetic insulation
cross arm
3.Generally material are Q235B
Equal-leg angle (kg/m) | unequal-leg angle | kg/m | |||
20*3 | 0.889 | 125*8 | 15.504 | 45*30*4 | 2.251 |
20*4 | 1.145 | 125*10 | 19.133 | 50*32*4 | 2.494 |
25*2 | 0.763 | 125*12 | 22.696 | 56*36*4 | 2.818 |
25*4 | 1.459 | 130*10 | 19.800 | 56*36*5 | 3.466 |
30*2 | 0.922 | 130*12 | 23.600 | 63*40*5 | 3.920 |
30*3 | 1.373 | 130*13 | 25.400 | 63*40*6 | 4.638 |
30*4 | 1.786 | 130*14 | 27.200 | 75*50*5 | 4.808 |
40*3 | 1.852 | 130*16 | 30.900 | 75*50*6 | 5.699 |
40*4 | 2.422 | 150*10 | 23.000 | 75*50*8 | 7.431 |
40*5 | 2.976 | 150*12 | 27.300 | 90*56*6 | 6.770 |
45*4 | 2.736 | 150*14 | 31.600 | 90*56*8 | 8.779 |
45*5 | 3.369 | 150*15 | 33.800 | 100*63*6 | 7.550 |
50*3 | 2.332 | 140*10 | 21.488 | 100*63*8 | 9.878 |
50*4 | 3.059 | 140*12 | 25.522 | 100*63*10 | 12.142 |
50*5 | 3.770 | 140*14 | 29.490 | 100*80*6 | 8.350 |
50*6 | 4.465 | 160*10 | 24.729 | 100*80*7 | 9.656 |
56*4 | 3.446 | 160*12 | 29.391 | 100*80*8 | 10.946 |
56*5 | 4.251 | 160*14 | 33.987 | 100*80*10 | 13.476 |
63*4 | 3.907 | 160*16 | 38.581 | 110*70*6 | 8.350 |
63*5 | 4.822 | 180*12 | 33.159 | 110*70*7 | 9.656 |
63*6 | 5.721 | 180*14 | 38.382 | 110*70*8 | 10.946 |
63*8 | 7.469 | 180*16 | 43.542 | 110*70*10 | 13.476 |
70*5 | 5.397 | 180*18 | 48.634 | 125*80*7 | 11.066 |
70*6 | 6.406 | 200*14 | 42.894 | 125*80*8 | 12.551 |
70*7 | 7.398 | 200*16 | 48.680 | 125*80*10 | 15.474 |
70*8 | 8.373 | 200*18 | 54.401 | 125*80*12 | 18.330 |
75*5 | 5.818 | 200*20 | 60.056 | 140*90*8 | 14.160 |
75*6 | 6.905 | 200*24 | 71.168 | 140*90*10 | 17.475 |
75*7 | 7.976 | 200*25 | 73.600 | 140*90*12 | 20.724 |
75*8 | 9.030 | 175*12 | 31.800 | 140*90*14 | 23.908 |
75*10 | 11.089 | 175*15 | 39.400 | 160*100*10 | 19.872 |
75*9 | 10.060 | 250*250*25 | 93.770 | 160*100*12 | 23.592 |
80*5 | 6.211 | 250*250*35 | 128.000 | 160*100*14 | 25.247 |
80*6 | 7.376 |
|
| 160*100*16 | 30.835 |
80*7 | 8.525 |
|
| 180*110*10 | 22.273 |
80*8 | 9.658 |
|
| 180*110*12 | 26.464 |
80*10 | 11.874 |
|
| 180*110*14 | 30.589 |
90*6 | 8.350 | unequal-leg angle(kg/m) | 180*110*16 | 34.649 | |
90*7 | 9.656 | 125*75*7 | 10.700 | 200*125*12 | 29.761 |
90*8 | 10.946 | 125*75*8 | 12.200 | 200*125*14 | 34.436 |
90*10 | 13.476 | 125*75*9 | 13.600 | 200*125*16 | 39.045 |
100*6 | 9.366 | 125*75*10 | 15.000 | 200*125*18 | 43.588 |
100*7 | 10.830 | 125*75*12 | 17.800 | 200*125*20 | 47.885 |
100*8 | 12.276 | 150*90*8 | 14.700 | 100*75*6 | 8.060 |
100*10 | 15.120 | 150*90*9 | 16.400 | 100*75*7 | 9.340 |
100*12 | 17.898 | 150*90*10 | 18.200 | 100*75*8 | 10.600 |
110*7 | 11.928 | 150*90*12 | 21.600 | 100*75*9 | 11.800 |
110*8 | 13.532 | 200*100*10 |
| 100*75*10 | 13.000 |
110*10 | 16.690 | 200*100*12 | 27.620 | 100*75*12 | 15.350 |
110*12 | 19.782 | 200*100*14 |
|
|
|
120*8 | 14.880 | 200*100*15 | 34.040 |
|
|
120*10 | 18.370 | 200*100*16 |
|
|
|
120*12 | 21.666 |
|
|
| |
Hot-dip Galvanized 11kv 33KV Electrical Cross Arm/Angle steel for Pole Line Hardware:
Usually we pack goods by box, wooden cases or according to client’s requirements to adjust. We
will be responsible for packing the stores suitable for transit by sea/ rail/ road so as to ensure their
being free from loss. Usually we export the product on Tianjin Port and Shanghai Port. We will do
our best to meet the client's requirements.
Hot-dip Galvanized 11kv 33KV Electrical Cross Arm/Angle steel for Pole Line Hardware:
How's the delivery time ?
Usually it will take about two weeks for the order of 100,000 sets for production
Tell me the standard of package?
For inner box and master carton are made as per international standards,and we can make
special design for you if need. Also if necessary, will be packed in pallet to avoid any damage.
Tell me if we received the bad products?
Send to us the bad products photos,we will send to you the new and the good products freely.
