10W Mini Solar Power Generator With DC 5v Ouput Charger

Specifications

Product Name: 10W Mini Solar Power Generator with DC 5v ouput charger

Configuration:

Solar Panel: 18V10W(Efficiency at around 18% and waterproof)

Battery: 12V7AH(Maintenance free lead acid battery)

Lamp: 3PCS DC 12V3W (Super bright LED bulb)

USB port: 2PCS to charge mobile phones, to apply DC fan, MP3, MP4 etc.

 10W Mini Solar Power Generator with DC 5v ouput charger

Application:

This product is a multi-function mini solar home lighting system.

It is suitable for house lighting in the place with plenty of sunshine while lack of electricity.

It also can be used as lighting for traveling, camping, outdoor work and other emergency lighting.

What’s more, it can use as a potable backup power/charger too, can charge for mobile, camera, DV, MP3, MP4, PSP, iPod..

Performance:

Energy saving and Environmentally friendly;

Easy to use & maintain;

Tiny design for easy carry;

Intelligent protection against overcharging, over discharging, over loading, electronic short circuit, unique anti-reverse;

Around 8 hours to charge the battery fully by solar panel(at STD condition);

Around 9 hours after the battery is fully charged;

Built-in Lead acid battery (maintenance-free), over 300 circle times using;

Efficiency of solar panel cells over 18%;

Battery indicator with touch switch;

Can be wall mounted for space saving.

Note: different altitude and different area have different effective sunshine time each day. The charging time will be changeable with it too. Better sunshine energy area, get a better charging effect.

Note:

1. If the system connection is well however the LED bulb still not light up, maybe there is no power for the battery, and need charge the battery from solar panel at daytime in time.

2. Please charge the battery from solar panel everyday to ensure battery power is sufficient.

3. Turn off the “switch” on the battery kit if you don’t use light and USB or it will have self power consumption.

4. If you don’t use the system for long time, please full charge it at least one time every 3 months to keep the battery performance good.

5.The LED lamp is DC12V, can’t be use for AC110V/220V. So it will break if use for city electricity.

Caution:

6.1 Please read the user manual carefully before using, the incorrect operation will damage the product.

6.2 Protect the product from drastic crash or throw

6.3 Keep the battery kit away from water or fire

6.4 Do not disassemble the battery kit or other components.

6.5 Do not drag the cable of the solar panel strongly, or it will come to poor contact.

6.6 Keep it away from Children.

Please full charge the battery at least one time.
