Product Details
| Place of Origin | Guangdong, China | Brand Name | Yetnorson | |
| Model Number | YNX-RG178-MCX-SMA |
Ten products with PE bag packaging of Angle Bulkhead Rf Coaxial
Product Description
Specifications
Angle Bulkhead Rf Coaxial1)Directly factory manufacture
2)High quality and fast delivery
3)Good Service
Angle Bulkhead Rf Coaxial product information
| RF 1.78 cable Interface RF cable with SMA Female to RA Mcx pigtail | Structure of product | |||||
| Connector Technical Characteristics | Frequency Range(MHZ) | 174~862 | ||||
| V.S.W.R | ≤1.50+0.02f | |||||
| Impedance (Ω) | 50Ω | |||||
| Insertion Loss | 0.6DB | |||||
| Plating | gold plated | |||||
| KV | 50±2 | |||||
| Insulator | PTFE | |||||
| RG Flexible Cables Technical Characteristics | Cable Type | UI-178 | ||||
| Center Conductor | 0.2 /Sliver Plated) | |||||
| Insulation Dimensions | Ø 0.5±0.1mm PTFE | |||||
| Screen Dimensions | Ø1.78 Sliver Plated | |||||
| Jacket Dimensions | Ø1.78 | |||||
| Nominal Impedance | 50Ω | |||||
| Environment Specifications | Operation temperature | -55~+150°C | ||||
| Operation Relative humidity | 55%~75% | |||||
| Testing voltage of spark | 2000V | |||||
| Testing voltage | 2000V | |||||
| Attenuation(Typical)(dB/m) | 470MHz | 0.31dB | ||||
| 665 MHz | 0.52dB | |||||
| 712MHz | 059dB | |||||
| 800 MHz | 0.61dB | |||||
| 862 MHz | 0.65dB | |||||
Angle Bulkhead Rf Coaxial Return loss test chart
Angle Bulkhead Rf Coaxial payment way
Angle Bulkhead Rf Coaxial shipping way
Why us
Angle Bulkhead Rf Coaxial Refund & Replacement
1. We can guarantee the product quality within one years .
2. If parts cannot work, we will return payment or replacement to you.
3. Any items must be returned in their original condition to qualify for a refund or replacement.
4. The buyer is responsible for all the shipping cost incurred.
Quality is essential to both of us, we believe that High quality, Low price,Mutual benefit will be good basis of our cooperation
