Home > Products > Folding gluing machine > Automatic folder gluer
Automatic folder gluer
- Shanghai
- T/T
You May Like
Product Details
| Product Type | Other, folding gluing machine | Processing Type | Other, folding gluing machine | |
| Place of Origin | Shanghai, China | Brand Name | Towin | |
| Model Number | HZH980FBP | Certification | CE |
Product Description
Specifications
folder gluer1.Folder gluer for carton & corrugated box
2.Straight line & crash lock bottom box.
3. 4/6 corner box.
folder gluer
¨ Max.Box blank width: 980mm
¨ Min.Box blank width: 160mm
¨ Substrate: Cardboard: 250-600gsm
Corrugated board: E flute
¨ Max.Speed: 200m/min
¨ Applicable glue: Water solvent glue
¨ Main motor power: 11kw
¨ Total motor power: 14.1kw
¨ Power supply: 380V/50Hz 3phases
¨ Machine weight: 6.5 tons
¨ Machine dimension: 14000X1300X1900mm(LxWxH)
¨ Feeder: Friction by belt with shaking motor
¨ Prebreaker: The first line 180 degree; The third line 135
degree
¨ Box type: Straight-line; Crash-lock bottom ( with auto kicker),
four corner box, six corner box
Straight line box
Position | HZH580 | |
A | MAX | 580 |
MIN | 80 | |
B | MAX | 580 |
MIN | 70 | |
C | MAX | 290 |
MIN | 40 | |
D | MAX | 580 |
MIN | 80 | |
E MIN | 10 | |
F MIN | 7 | |
Crash lock bottom box
Position | HZH580 | |
A | MAX | 520 |
MIN | 160 | |
B MAX | 580 | |
C MAX | 260 | |
D MAX | 580 | |
D MIN | 80 | |
E MIN | Refer to G | |
F MIN | 7 | |
G MIN | 22 | |
Four corner box
Six corner box
