7W 9W 11W 13W 18W uv lamp electronic ballast

Specifications

uv lamp electronic ballast

1.for UV lamp 7W,9W,11W,13W,18W.

2.power factor selection:PF>0.6 or PF>0.98

2.Long life low current wave peak

3.High Power factor

4.Low Total Harmonic Distortion,low lamp current crest factor

5.EMC effection:Pass

6.Comply to EN 61347-1,EN 61347-2-3,EN 55015,EN 61547,EN 61000-3-2

7.Start mode :Preheat start or instant start selectable
8.Average useable life:>20000hrs

9.End of lamp life protection.

10.Apply plug- in wiring terminal, convenient installation

11.AC voltage range(min-max)170-264V or 90-130V

DC voltage range(min-max)198-276V
12.Energy Efficiency:EEI=A2
13.Safe switch off of defective lamps
14.Automatic re-start after lamp change.
15.Protection against lamp fault condition.
(contain End of lamp life protection.)
16.End of lamp life,over-heat,over-load protection
17.Ingress protection:IP20

Features of electronic ballast:

1. Favorable low voltae starting performance,start the lamp under 130v low voltage,power supply.

2. Apply plug-in wiring terminals,conbenient installation apply electronic soft start technology; outstanding performance,long life low current wave peak ratio,

3. The electromagetic compatibility reaches the national standard,high power factor >0.98
