CNHTC Sinotuck 8m3 Howo Mixer Trucks for Sale

Main information

Product Name

Sinotruk howo 6x4mixer truck

Product Model

Howo

Chassis model

howo

Payload

30000-40000kg

Curb weight

16850

Drive Model

6x4

Drive Type

Left-hand

Vehicle Body Color

Red/White/Green(optional)

Engine

Brand

howo

Model 1

WP615 serial 266hp

6 cylinder in-line with water cooling & inter-cooling, direct-injected technology

Displacement(L)9.726L

Max.Power(kW)196

Rated power Rev(RPW)2200

Maximum Torque(N*m)/Rev(r/min)1100/1200~1400

Model 2

300hp

Model 3

336hp

Model 4

WP615 serial 371hp

6 cylinder in-line with water cooling & inter-cooling, direct-injected technology

Displacement(L)9.726L

Max.Power(kW)273

Rated power Rev(RPW)2200

Maximum Torque(N*m)/Rev(r/min)1500/1100~1600

Emission Standard

Euro II

Clutch

Model

Φ430 diaphragm spring

Transmission

Brand

Sinotuck

Model

HW15710 (10 forward, 2 reverse, manual)

Rear Axle(drive axle)-Model

HC16

Front Axle-Model

HF9

Cabin type

HW76

Cabin

With A/C, Radio, Bunk

Steering System

ZF8098

Wheelbase (mm)

1800+3200+1350

Wheel/Tire

Type

Nylon tire

Model

12.00-20

Tire number

10+1

Dimensions

Overall (mm)

10360×2500×3980

(L×W×H)

Body interior (mm)

8-15cbm

Front overhang/Rear overhang(mm)

1500/2510

Approach/Departure Angle(°)

16/20

Max. Speed (km/h)

90

Concrete mixer truck standard configuration technician information (8-15cbm)

If you have any need,pls tell me.

Mixer drum parameter

Tanker Material:16MnQ345

Filling speed (M3/min) ≥3

Unloading speed (M3/min)≥ 1.2

Discharge reside rat( %)≤ 0.5

Mixer drum rotation speed(rpm) 0~12

Driving system

Reducer:Italy Italy PMP

Hydraulic pump: Italy PMP

Hydraulic motor: Italy PMP

Heat device :changzhou or wuxi (made in china)

Water supply system

Tank volume:400L

Air pressure water supply

Operating system

Model:linkage operation
