Hot Sell!!! H.264 4ch ip Camera Nvr
US$ 31 - 33
/ Piece
5 Pieces(Min. Order)
- shenzhen
- Credit Card
You May Like
-
HOT H.264 16CH Realtime NVR For IP Camera Recording Can Support 2HDD
-
HOT!!!economic 8ch 1080P/13ch 960P/16ch 720P Realtime NVR Support 2HDD
-
Hot Hi 3521 H.264 8ch 1080P/16ch 960P/16ch 720P Realtime NVR
-
Hot Sell!!! H.264 Full 4ch 960p Nvr With Free P2P
-
Hot Sell Casing H.264 4ch ip Camera Nvr Support PTZ 1HDD
-
Hi3520D 8ch NVR With ONVIF 2.4 HDMI
Product Details
| Place of Origin | Guangdong, China | Brand Name | antai | |
| Model Number | NVR-3704R-S |
Product Description
Specifications
2ch 1080/4ch 960P/4ch 720P Real Time Recording, 1ch 1080P/960P/720P realtime playbackProduct Description
| Model | Model | 4 Channel H.264 NVR |
| NVR-3704P (A,K,R,L,Y,W)-S | ||
| Board Model | PCBA-AT-NVR-B3515AH-4S | |
| Picture | Board Picture | |
| Rear Board | ||
| System | Main processor | Industrial grade embedded micro controller chip Huawei Hisilicon chipset Hi3515A |
| Operating system | Embedded LINUX operating system | |
| System resource | Multi-channel real-time recording synchronously, multi-channel real-time playback, multi-channel multi-user network operation, USB back up. | |
| Display | Operation interface | 16 bit real color GUI interface support mouse operation |
| Multilingual Language | YES, supporting 14 kinds of languages | |
| Display screen | 1/4 screen | |
| Video | Image encode | H.264(Main Profile) |
| Monitor quality | Monitor:D1; VGA&HDMI( 1920*1080;1280*1024;1280*720;1024*768) | |
| Playback quality | 1080P/960P/720P | |
| Encode capability | 2ch1080P/4ch 960P/4ch720P | |
| Decode capability | 1ch 1080P/960P/720P@25fps | |
| Audio | Audio compression | G.711A |
| Record and playback | Record mode | Manual, alarm, motion detection, timing |
| Snapshot | YES | |
| Local playback | 1ch 1080P/960P/720P@25fps | |
| Video search | Time, date, event, channel search | |
| Storage and back up | Space Usage | Video 720P:10G~42G/day*channel,1080P:20G~80G/day*channel,audio 691.2M/day*channel |
| Video storage | Local Hard Disk, Network | |
| Back up mode | Network backup, USB portable HDD, USB (FAT32 form) | |
| Interface | Video input | 4ch IP Camera |
| Video output | 1ch BNC(1.0Vp-p,75Ω), 1ch VGA , 1ch HDMI | |
| Audio input | ———— | |
| Audio output | 1ch RCA (200-3000mV,5KΩ) | |
| Alarm input | NO | |
| Alarm output | NO | |
| Network port | 1*RJ45 10/100 Base-T self-adaptive Ethernet port | |
| PTZ control | 1*RS485 port, Support more than 5 kinds protocols. | |
| USB port | 2* USB 2.0 port | |
| HDD port | Accommodates 1 SATA HDD (1 HDD capacity up to 2TB) | |
| Wireless Port | ______ | |
| User | User level | Admin |
| User right | Users can set different permissions (How to use please refer to the manual book) | |
| Password protection | YES | |
| Remote | Remote Independent Operation | YES |
| Download records | YES | |
| Remote Event Trigger Recording | YES | |
| CMS | CMS Software for multiple DVR (up to 255 DVR simultaneously) | |
| Browser | Internetie32-bit,360,Sogou,Google, Mozilla Firefox | |
| Live Audio | YES | |
| On-line user | Max.10 | |
| Mobile Surveillance | YES (Supporting iPad, iPhone,Android;iPad, iPhone, Andriod remote playback function ) | |
| Network Protocol | DHCP/ADSL,PPPOE, SMTP,TCP / IP,DDNS,Wireless dial,WIFI,P2P | |
| Alarm | Motion detection | FTP/YES |
| Event Notification | ||
| Pre-alarm Recording | YES | |
| Video loss | Video loss notification | |
| Other | IR remote controller | Remotely control DVR and PTZ cameras via IR transmitter (IR receiver built-in) |
| Remote control | YES | |
| Cooling fan | No | |
| Tour | YES | |
| Power Source (±10%) | DC 12V /2A | |
| Power Consumption (±10%) | <10W(without HDD) | |
| Operating Temperature | 0°C ~ +55°C | |
| Dimensions (mm) ** | 250mm(L)* 210mm(W)* 45mm(H) | |
| System Recovery | System auto recovery after power failure | |
| Package | Net Weight | 0.88kg±0.1kg |
| Carton Box Size | 5units packaging:358mm(L)* 83mm(W)* 270mm(H); 10units packaging:325mm(L)* 80mm(W)*255mm(H) ; | |
| Package Size | 5units packaging:440mm(L)* 375mm(W)*285mm(H) ; 10units packaging:415mm(L)* 335mm(W)*525mm(H) ; | |
| Gross Weight | 5units packaging:7.0kg±0.5kg; 10units packaging:13.5kg±0.5kg; | |
| *The specifications are subject to change without notice. | ||
| ** Dimensional tolerance: ±3mm | ||
Company Information
FAQ
Our Services
Packaging & Shipping
Carton Box Size:5units packaging:358mm(L)* 83mm(W)* 270mm(H) 10units packaging:325mm(L)* 80mm(W)*255mm(H)
Package Size: 5units packaging:440mm(L)* 375mm(W)*285mm(H) 10units packaging:415mm(L)* 335mm(W)*525mm(H)
Gross Weight:5units packaging:7.0kg±0.5kg 10units packaging:13.5kg±0.5kg
