2016 New Technology High Quality 3 rolls and 4 rolls Rubber Calender machine hot sale

2016 New Technology High Quality 3 rolls and 4 rolls Rubber Calender machine hot sale

2.Rubber sheet cooling machine is followed after open type mixing mill and calender machine, finished warm rubber sheet put into cooling machine, can be cooled quickly.

Technical parameters:

  1. 3-roll rubber calender machine

Model XY-3I 250X720

Dia of roll:  250mm

Working length of rolls:  720mm

Roll ratio : 1:1:1

Linear speed of medium rolls: 0-20m/min

Rolls gap adjusting range: 0 -10mmcan be adjusted

Gap adjusting type:  motorized adjusted

Reducer:  Hard surface gear reducer

Width of calendaring rubber sheet:  550mm

Min.thinckness of calendaring rubber sheet: 0.2mm

Roll linear speed:  5-18m/min

Motor power:  18.5 kw (Frequency conversion motor)

Roller rotation speed:  Frequency converter adjustment

Main electrical components:  CHINT brand of China famous

Weight: 3100kg

oling machine with 9 rolls

Diameter of cooling rolls:  320mm

Working length of cooling rolls:  630~800mm

Quantity of cooling rolls: 9 pcs

Cooling roll linear speed:  0-18m/min

Motor power:  4 kw (Frequency conversion motor)

Cooling Roll rotation speed:  Frequency converter adjustment

Cooling rolls material: 304 stainless steel

Main electrical components:  Famous Brand

Weight: 1500kg

3. Fabric or Plastic film let off device

Working length of let off:  800mm

Square steel: 30x30mm

Control type: Magnetic powder brake

4.  Rubber sheet winding device with double positions

Working length of winding:  800mm

Square steel: 30x30mm----2pcs

Motor power:  3 kw (Frequency conversion motor)----2sets

Winding speed:  Frequency converter adjustment-----2sets

Control type: Magnetic powder clutch----2sets

Main electrical components: Famous Brand

Our Advantage:

One year guarantee for whole machines(this service is superior than any other suppliers)

24 hours technical support by email

Calling or Door - To -Door service.

Provide videos for each machine.

we will send one engineer to your factory to guide installation and test running the production line, until you can operate the machine skilled.
