YEESO Large Version LED Mobile Stage Truck YES-C40 For Sale, Outdoor Advertising, Road Show

Chassis

Brand

SCGC

External dimension

12000mm×2535mm×2650mm

Curb weight

10000KG

Gross mass

26000KG

Hydraulic Lifting & Supporting System

Hydraulic lifting system

Electric putt (Germany technology)

Lifting height: 2000mm,afford 5T,synchronous error:1mm

Hydraulic supporting system

It can goes up 800mm,each afford 10T,its wind-proof level can reach to maximum level 8 when screen is lifted up

Extreme Super Silent Generator Set

External dimension

1510mm×900mm×1060mm

Power

16KW

Power type

KIPOR

Number of cylinders

Water-cooled inline 4-cylinder

Air displacement

3.595L

Bore*stoke

114mm×120mm

LED screen

Main Screen size

4800mm×2400mm

Module size

160mm(W) ×160mm(H)

Chip

R:GUANGLEI; G,B:SILAN

Pixel pitch

10mm

Brightness

≥6000cd/m²

Max power consumption

1200W/m²

Power consumption

Average: 600W/m²

Life span

100,000hours

Power Supply

Input voltage

Three phases, five wirings,380V

Output voltage

220V

Electrical current

50A

Power consumption

Average:0.5wh/m²

Multi-Media Control System

Industrial PC

Processor: Dual Core CPU; Display card: 512; Hard Disk:500G; CD-ROM: DVD; Internal storage:2G

Power amplifier

Unilateral power output:200W*2

Monitor

KVM 15-inch LCD display

Control system of LED screen

LINSN/ZHOGNQING (technology of point by point correction)

Speakers

Max power consumption:200W×4

Outer Frame and Inner Decoration

Cold rolled metal plate

1.5mm

Surface car baking varnish

Pure white

Inner decoration

Fire Retardant Board

Waterproof processing

Vehicle plastic irrigation processing
