J32 CNC Fresadora
- QINGDAO
You May Like
Product Details
| Condition | New | Type | Turning Center | |
| CNC or Not | CNC | Automatic Grade | Automatic | |
| Max. Swing Diameter | 195mm | Place of Origin | Shandong, China | |
| Brand Name | pulute | Model Number | j32 | |
| Voltage | 380v | Power(W) | 4kw | |
| Dimension(L*W*H) | 1420*1120*1750mm | Weight | 800kg | |
| Certification | CE, ISO9001, ISO14001 | After-sales Service Provided | Overseas third-party support available |
Product Description
CNC fresadora
| CNC fresadora | J32 CNC lathe |
| Max. swing over bed | Φ190 mm |
| Max. swing over cross slide | Φ80mm |
| Max. processing length | 200 mm |
| Thu-hole dia. of spindle | Φ37 mm |
| Drawing pipe dia. | Φ32 mm |
| Spindle taper | A2-4 |
| Spindle speed | 150-2500 rpm |
| Spindle motor power | 3 kw |
| X/Z axis travel | 300/320 mm |
| X/Z axis torque | servo 1/1 kw |
| X/Z axis rapid feeding speed | 8/10 m/min |
| X/Z axis position accuracy | 0.01/0.015 mm |
| X/Z axis repeatability | 0.012/0.013 mm |
| Tool bar section | 16*16 mm |
| Tailstock sleeve dia. | Φ45mm optional |
| Tailstock sleeve travel | 90 mm optional |
| Tailstock taper | MT4# optional |
| N.W. | 800 kg |
| Machine dimension (L*W*H) | 1450*1100*1600 mm |
1. J32 CNC fresadora standard accessories
pneumatic collet and spindle drawing pipe ( some suppliers do not offer this as standard accessories)
4 station gang type tool post
a full set of lubrication system
a full set of coolant system
Lighten system
tools and tool box
GSK 928TEA NC system
2. J32 CNC fresadora optional accessories
5 " manual three-jaw chuck
5 " hydraulic chuck, hydraulic station, hydraulic cylinder
Hydraulic collet, hydraulic station, hydraulic cylinder
manual tailstock
Auto-bar feeder( two types: short bar and long bar)
chip conveyor
Fanuc 0I mate TD, Siemens 808d, GSK980TDC
3. To choose the most suitable and economic CNC lathe model, please kindly tell the following
info. in details
piece material and usage, solid type or hollowed type ( pipe type),
2.list all of outer diameters and inner diameter,
3.drawings is best to be sent to us too.
Click " send " now and learn more about our products.
