Mini Gps Tracker With Real Time Tracking for Vehicle Device TK116

Specifications

A GPS tracking device empowers a person using it, to precisely locate a vehicle or person or any thing that it is attached to. It makes use of the Global Positioning System to record and store the position within the device. The information may also be transmitted to a central location database via a cellular (GPRS), radio, or satellite modem installed in the tracking unit.
1.real time tracking no matter anytime anywhere
2.gps tracking device

1. Temperature and fuel alarm GPS tracker for vehicle
2.Accurate positioning
3.SOS,cut off  fuel/Power

4. The mainboard over-current protection

Environment for use
1,Limited working temperature:-20°C~80°C
2,Storage temperature:-45°C~90°C
3,Humidity:<95%
4,Atmospheric pressure:86kPa~106kPa
5,Make sure the terminal is installed in rainproof
and snow-proof places.

6.200MAh battery

echnical Specifications

Basic Specifications:
Voltage 12VDC/24VDC
Standby Current <3mA
Work current <30mA
GPS positioning
accuracy 15m
GSM positioning
accuracy 100m
GPS Frequency 1575MHz
GSM Frequency 850/900/1800/1900MHz
Hot/warm/cold start time <3s,<15s,<60s
Dimensions (mm) L*W*H :
79.2X38.5X13.5
Weight 45 g

Product Features
1.Supports quad bands, i.e.
850/900/1800/1900MHz, universal in
the world.
2.Wide Input Voltage:6-24V DC.
3.Supports single positioning and feedbacks
position via GPRS at setting times.
4.Supports vehicle positioning and tracking.
5.Supports ACC status checking and vehicle status
notifying.
6.Use relay to remote control the vehicle..
7.Use SOS button for SOS call.
8.Use external MIC to monitor remotely

9.it could change the IMEI number by SMS.

10,for the software ,it could upgrade by remote from server .

We have our software and hardware engineers team .We support ODM and OEM orders .
