good quality sleeve anchor with hex bolt made in handan hebei

 • About the inquiry : we wil reply within 24 hours .

 • Guarantees/Warranties/Terms and Conditions : We guarantee product quality and take responsibility for the defects caused by manufacturing.

1. Good after sales service. Any small problem happening will be solved at the most prompt time;

2. Many years of export experience;

3. Specifications list is available upon your request

4. Welcome to send enquiry, we will reply soon.

5. Prompt shipment with professional documents

6. Custom packing, with photo before shipment

7. High quality and competitive price.

Company Information

1.Our company is a professional manfacturer of hardware fasteners.our factory was founded in 1992,we have taiwan high-speed molding machine 11B,14B,17B,19B,24B. We are specificizing in the export business of fasteners which enjoys great popularity in the world market. You could contact us if any item is interest to you. We will do our best to meet you requirements.

2.We have many years of experience and specializing in fastener,Quality is stable for mass production.

such as:ANSI wedge anchor  DIN wedge anchor

              ANSI drop in anchor    Din drop in anchor   BS drop in anchor

              chemical anchor ,sleeve anchor (hook ,eye ,flange nut ,hex bolt )

              three-fixed anchor   four fixed anchor

our packing is :small box+carton +pallet

                         bags+pallet

                         bulk bags

                         on customer demand

expansion anchor bolt / anchor bolt / expansionscrew

material: carbon steel Q195 or Q235

standard: DIN

surface treatment: elector galvanizing /  hot dip galvanized

color: blue white or yellow, plain

mark: according to your requirement

origin: Handan, Hebei, China

sizes:

DIN standard:

M6: 50,60,65,80,100

M8: 60,70,80,90,100,120,150

M10: 60,70,80,90,95,100,110,120,150,170,200

M12: 80,90,100,110,120,130,150,180,200

M14: 100,120,150,180,200

M16: 100,120,145,150,180,200,250,300

M18: 150,180,200,250,300

M20: 150,180,200,250,300

M22: 150,200

M24: 150,200,250,300

Installation steps

1. Using a hammer drill and carbide tipped drill bit, drill a hole the same diameter as the anchor diameter,  deeper than the expected embedment.

2. Clean out hole of all debris.

3. Set the nut flush with the top of the sleeve anchor.

4. Insert the sleeve anchor through the fixture into the hole in the base material until the washer and nut are tight against the fixture.
