VS100 Vehicular Thermal Camera/Specialty Thermal Systems/Auto Thermal Camera

Items

Core

VS100

Detector characteristic

Detector

Uncooled amorphous silicon FPA

Array format/Pixel pitch

384×288 / 25um

Sensitivity

≤80mk at f/1.0 300K

Frame rate

50Hz

Spectral range

8~14um

Imaging process

Shutter calibration

No shutter technology

Booting time

<3s

Noise reduction

Digital filter

Image resolution

768×576

Lens option

18.8mm, F=#0.9

Thermal imaging adjustment

Polarity

White hot /Black hot

Mirror image

Horizontal/Vertical

Zoom

×2,×4

Manual Gain

Cycle adjustment

Auto Gain

Auto adjustment

Power

Working voltage range

DC: +6V~+51V

Typical voltage

DC:12V

Power consumption

1W

Anti reverse voltage

Yes

Anti over voltage

Yes

Environmental parameters

Working temperature

-40ºC~+60ºC

Storage temperature

-57ºC~+105ºC

Humidity

5%~95% Non condensing

Vibration and shock

Vibration:GJB 150-16 2.3.1

Axial:GJB 150-18

Experiment:7 100g/6ms

Lateral:GJB 150-18

Experiment:5 40g/11ms

Anti temperature impact

-5ºC/min(-40ºC~+60ºC)

Physical parameters

Weight

500g(with bracket)

Dimension

62mm×62.5mm×89mm

Interface

Power input port

Yes

Serial port

RS-232

Analog video output

BNC(75Ω);Support dual video output

Digital video output

16Bit(50Hz)

Keyboard

4 buttons keyboard
