Home > Products > Cutting Machine > Yuyu-701(1300) PE Film Cutting Machine
Yuyu-701(1300) PE Film Cutting Machine
- Shanghai
- T/T
You May Like
Product Details
| Condition | New | Application | Other, Machinery & Hardware | |
| Packaging Type | Case | Packaging Material | Plastic, Wood | |
| Automatic Grade | Automatic | Driven Type | Pneumatic | |
| Voltage | 220V/380V | Power | 5HP | |
| Place of Origin | Jiangsu, China | Brand Name | YUYU | |
| Model Number | 701 | Weight | 1.5T | |
| Dimension(L*W*H) | 3500mm*1300mm*1500mm | Certification | CE/ISO | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
PE Film Cutting Machine: cut insulation tape/PVC/OPP/PE/Masking tape/Double-side tape/Plastic films/window films/3M tape.
1.Application field:
Suitable for cutting various log roll materials such as Insulation tape/polyester tape/ PVC/OPP/PE/Masking tape/Double-side tape/Plastic films/windows film/3M tape/fiberglass mesh tape…etc.
2.Features:
1. Centralized control panel: all operation controls. For this machine are centralized in a control panel.
2. Control panel provides major functions: material and blade running speed (LED screen display), width counter, number of cuts counter.
3. Silicon lubricating system prevents the blade from sticking on adhesives and allows smooth cutting at all times. Silicon liquid is re-circulated.
4. The blade is back pressure controlled through an air and hydraulic combination, giving maximum cutting stability and fast blade retract after each cut, cutting pressure can be easily adjusted to suit various types of materials.
5. Cutting circular knife and main shaft power force adopted with AC step-less adjusting motor and available in any rotating direction.
6. Cutting width setting up controlled by servo motor adjustable equipped with ball screw to secure accurate size.
7. PLC programmable control.
3.Technical parameters:
Max. cutting diameter | 270mm |
Max. cutting speed | 35cuts/min |
Max. length of cut | 1300mm or 1600mm |
inside diameter of paper core | 32-76.2mm |
cutting width | 3-1600mm |
main motor | 5HP |
blade drive motor | 3HP*6P(servo motor) |
blade diameter | 150-350mm |
blade speed | 360-1800rpm |
weight | 1150kg |
machine dimension(L*W*H) | 3500*1300*1520mm |
Contact Us
- Taicang Yuyu Plastic Products Co., Ltd.
- Contact nameManjun Zhao Chat Now
- Phone86-512-53412888
- AddressNo.23 Yingchun Road,Xinhu Town ,Shuangfeng Township,Taicang District,Suzhou City,Jiangsu Province, Suzhou, Jiangsu
