ZP Series of Rotary Tablet Press Machne With Model
- Dalian China
You May Like
Product Details
| Condition | New | Place of Origin | Liaoning, China | |
| Brand Name | SINOPES | Model Number | ZP-15 | |
| Type | Rotary Tablet Press | Production Capacity | 70000/h | |
| Max. Pressure(KN) | 100KN | Max. Tablet Thickness(mm) | 20mm | |
| Max. Tablet Diameter(mm) | 25mm | Voltage | 220/380V | |
| Power(W) | 5.5KW | Weight | 675KG | |
| Dimension(L*W*H) | 660*690*1620MM | Certification | CE CGMP | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Brief Introduction of the Machine
1. Stainless steel main machine housing.
2. The parts contact with the powder are made of stainless steel.
3. PLC touch screen controller
4. There are oil-leak proofs and dust proof devices installed in die holes.
5. No-handwheel operating system
6. Sensor system – alarming first and then stopping machine when any one is happened as following situation.
- without powder or pellet
- open the plastic door
- Motor of Dust collector is overload
- Inverter is in trouble
- Lack of lubrication
7. Electrical control system.
A. Rapidity display.
B. Alarm display.
C. Main motor state display
Main configuration table
PLC | OMROM |
Touching Screen | EVIEW |
Sensor | OMROM |
Main Motor | |
Linear Bearings | Japan HIT |
Proximity Switch | OMROM |
Oil Lubrication | BIJUR DELIMON |
Contactor | France Schneider |
Protector | France Schneider |
Model | ZP15 | ZP17 | ZP20 | ZP25 |
Punch & die type(EU) | D | B | BB | BBS |
Number of dies | 15 | 17 | 20 | 25 |
Max diameter of tablet (mm) | 25 | 16 | 13 | 11 |
Max diameter of abnormal tablet(mm) | 25 | 18 | 16 | 13 |
Maximum pre-pressure (KN) | 12 | |||
Maximum main pressure (KN) | 100 | 80 | 80 | 80 |
Maximum filling depth (mm) | 20 | 16 | 16 | 16 |
Maxoutput (t/h) | 70000 | 80000 | 95000 | 118000 |
Idle load noise dB(A) | <75 | |||
Power of main motor (KW) | 380V 50HZ 5.5KW | |||
Size of machine (mm) | 660×690×1620 | |||
Net weight of machine (kg) | 675 | |||
Price and payment term
Machine name | Model | USD Price FOB China |
Tablet press machine | ZP15~ZP25 |
|
Dust collector | XGB-220 |
|
Deduster | SP-300 |
|
IQ/OQ with the machine. | ||
SAT SAT (site accepting test in clients place) accommodation HOTEL and food on account client | ||
Delivery 30working days from the receipt of down payment and samples of products to be operated on the machine. (The actual delivery time depend on your order) | ||
Payment terms 30% down payment by telegraphic transfer, 70% balance by T/T before shipment | ||
Validity of this quotation: 90 days | ||
After-sale service
We will send our technical enginner to your country to do installation, and training.
After our machine arrived to your country, we can send our technician to do the installation, your part do not need to pay any training fee, and time fee. Your part only bear the airplane fee and the local accommadation.
One year free spare part free with our machine.
One year warranty.
