Color Steel Roofing /acrylic Overglaze Tile /roof Zinc Tile
- QINGDAO
- T/T Credit Card
You May Like
-
PPGI Coil Manufacture Galvanized Ppgi Coil and Supplier in China
-
GGI/PPGI Steel Coil
-
Best Sale ! PPGI Steel Coil With High Quality and Best Price
-
gI and PPGI ,H /R and C/R Sheets Type and Galvanized Surface Treatment Ppgi/ gi Steel Coil
-
CGCC Color Coated Ppgl,prepainted Galvanized Steel Ppgi
-
Factory Wholesale Superior Quality Prepainted Galvanized Steel Coil/PPGI Steel Coil
Product Details
| Place of Origin | Shandong, China | Brand Name | deqiang | |
| Model Number | yx18-215-860 | Material | Coloured Glaze | |
| Type | Bent Tiles |
Product Description
Product Description
Prepainted galvanized steel coil / corrugated metal roofing sheet / ppgi corrugated plate
1. Thickness: 0.2-0.7mm
Standard: AISI, ASTM, GB,BS,DIN ,JISmaterial :SGCC SGCH SGHC
Width: 600-1250 mm
Standard | ASTM A653, JIS G3302,GB/T3830-2006 |
Grade | DX51D,SGCC etc |
Thickness | 0.2mm--0.7mm |
Width | 665mm 680mm 750mm 820mm 840mm 860mm 1020mm 1025mm 1050mm 1075mm |
Base metal | Galvanized steel coils,Galvalume steel coil |
Zinc coating | 40-120gsm |
Lenght | 1830 2440 3660mm or customered |
Coating thickness | Top:13-25um back:7-10um |
Color options | Ral number or as per your request |
Packing | Standard seaworthy export packing: 3 layers of packing, inside is kraft paper, water plastic film is in the middle and outside GI steel sheet to be covered by steel strips with lock, with inner coil sleeve. |
Delivery | Within 10-15days after signing contract |
Price | FOB&CNF&CIF price |
Payment terms | TT or L/C |
Monthly supply | 30000MT per month |
Application: | workshop, storeroom, roofing,kiosk... |
2. The advantage of product are stated as below:
1.Increased supporting strength
2.Reduced project cost
3.Light weight
4.Easy and fast for installation
5.Durable: 12-20 years
6. Fire,Water Proof
7.Multiful color choices
3. If you are interested in it, please kindly advise:
1. color & thickness & length & quantity
2. delivery time
3. packing request
4. other request details
Galvalume/Color Coated Galvalume Roofing Sheets, Metal Corrugated Roofing Material
The hot dip galvalume steel is a kind of coated steel. With the cold rolled steel of different strength and thickness as substrate, it is produced through applying Al-Zn coat on both faces by hot dip process. In its coating, Al accounts for about 55%, Si 1.6%, while the remaining is Zn. It enjoys both the physical protective feature and durability of Al and the electrochemical protective property of Zn. And its surface has bright silver color and regular embossed-like figure, which are highly decorative.
More than 50 worldwide customers none-risky experiences approved.
Yogic has been exporting steel coils to more than 50 countries directly. Our long term supply extends to USA, UK, Germany, Italy, Spain, Belgium, France, Poland, Greece, Ukraine, Belarus, Russia, Turkey, Egypt, Saudi Arabia, Iran, Ethiopia, Niger, Brazil, Colombia, Chile, Peru, Australia, New Zealand, etc
Prepainted galvanized steel coil / corrugated metal roofing sheet / ppgi corrugated plate
6. Tools you'll need when install corrugated steel sheet:
1)Sheets of corrugated metal 2)Metal ridge caps 3)Roofing felt (if needed) 4)Nails
5)Hex screws 6)Washers 7)Hammer 8)Drill
PPGI Coils, Color Coated Steel Coil, RAL9002 White Prepainted Galvanized Steel Coil
| Thickness | 0.12mm-3.0mm |
| Width | 665mm-1220 (AC) |
| Zinc coating | 40g-150g/m2 |
| Length | 1000mm-6000mm as your required |
| Tolerance | width:+/-5mm,thickness:+/-0.02mm |
| Spangle | regular spangle,big spangle,minimized spangle or all kinds of color coated |
| Pitch | 76mm or as required |
| Wave height | 18mm or as your required |
| Wave number | from 8 to 12 |
| Type | steel plate |
| Weight of each package | about 3mt |
| Technology | cold rolled |
| Surface treatment | galvanized,chromated,bright finished,unoiled(oiled) |
| Material | SGCC,SGCH |
| Standard | ASTM,JIS,DIN,GB |
| Packing | export standard packing,packed with moisture resistant paper and metal wrapping,securely tied for export,on metal skids |
Product Description
1. ISO System
2. SGS and BV Audited company.
3. Industry experience over 10 years.
4. Management Systems-Internal Software
5. Raw Material inventory -Over 800 Mertic Tons.
6. Shipment of goods -More than 30 countries worldwide.
7. We have the most convenient transport and prompt delivery.
8. We offer competitive price with best service.
9. We have high technical production line with top quality products.
10. We have win high reputation based on best quality products.
Prepainted galvanized steel coil / corrugated metal roofing sheet / ppgi corrugated plate
Products process:
Un-coiler------stitching machine-----barrels-----tension machine-----uncoil-----alkali washing and degreasing-----cleaning----drying----passivation-----drying---- primary coating----drying----primary coating drying----top coating---top coating----cooling----coil----packing and warehousing.
Prepainted galvanized steel coil / corrugated metal roofing sheet / ppgi corrugated plate
Advantages for heat insulation Corrugated Roof Sheet
1. Corrosion resistance.
2. Color stable.
3. Sound absorption and heat insulation.
4. Good water resistance.
5. Fireproof resistance.
6. Easy to install.
7. Good impact and low temperature resistance.
8. Light weight.
9. Stable volume.
10.Environment friendly and energy saving.
Technical data for heat insulation Corrugated Roof Sheet
| Item | Content | Result | Standard |
| Environment | Pollution or environment friendly | No asbestos and Environment friendly Recycling material | GB6566-2001, A standard good for Environment |
| Heat distortion temperature | Under 70.0°C | No change | GB/T1634-2004 |
| Vicat softening temperature | Under 75.2°C | No Softening | GB/T1633-2000 |
| Hard to burn | B1 Grade | Oxygen index: 32.4 | GB/T2406-1993 |
| Vertical Burning | FV-0 | FV-0 | GB/T2408-1996 |
| horizontal Burning | FH-1 | FH-1 | GB/T2408-1996 |
| Impact Resistance | no crack | 0/10 | GB/T8814-2004 |
| Density | 1.75-1.95 | 1.778 | GB/T1033-1986 |
| Corrosion-resistant | Acid (HCL,H2SO4,HNO3)5% | No change | QB/T3801-1999 |
| Alkaline(NaOH)5% | No change | QB/T3801-1999 |
Installation Process for heat insulation Corrugated Roof Sheet
-Easy installation,similar to steel roofing sheet.
-Clients can get installation Video when once purchase product.
-Provide full course of follow up service.
1.Q:You are factory or trading Company?
A: We are a Factory with 8 years of experience specialized in cold rolled coil, galvanized steel coil, ppgi and corrugated roof sheet with high quality, competitive price and good service.
2. Q:what is the MOQ.?
A:Generally speaking, the MOQ is 25 metric ton per size, if your quantity is small , we can supply you from our stock .
3.Q: I need sample, could you support?
A: We can supply you with the sample for free, but the delivery charges will be covered by our customers. For avoiding the misunderstanding, it is appreciated if you can provide the International Express Account for Freight Collect. Also you can have a visit to us, welcome to JNC!
4.Q: How to know the Quality Guarantee:
A: We suggest you to visit our company to check the quality. And also the third inspection can prove our products quality.
B :We will attach some relevant photos via email to show our office and products to you
| Prepainted Steel Coil | ||||||||
| BASIC MATERIAL | CHEMICAL COMPOSITION % | MECHANICAL PROPERTIES | ||||||
| C | Si | Mn | S | P | T.S | Y.S | E.L | |
| MPA | MPA | % | ||||||
| GL/GI | 0.06 | 0.02 | 0.22 | 0.018 | 0.017 | 346 | 360 | 31 |
| PAINT COATING | MEK | GLOSS | PENCIL RIGIDITY | BENDING TEST | REVERSE IMPACT | INSPECT RESULT | ||
| μm | ||||||||
| 30 | OK | 60% | 3H | 3T | 9J | OK | ||
| Standard :GB/T 12754 2006 | ||||||||
Corrugated roofing sheet/roofing products/galvanized sheet metal roofing
Jinan deqiang coated steel
contact : tom yu
cell : 13583135936
whatapp:86-13205403820
skype: smile6869
mail: hnymetal @
