HYDROSILA (hydraulic Power) Planetary Gear Reducers
- Qingdao
You May Like
-
3-14 Cubic Mixers Trucks Main Hydraulic Reducers
-
Hydraulic Motor Test Stand
-
High Accuracy MYHT-1-4 Portable Appliance Tester
-
Jinan Highland Portable Hydraulic Pump Pressure Calibrator
-
MYHT Portable Booster Pack for Hydraulic Pump and Motor
-
New Portable Hydraulic Flow Meter for Sale of Pump Treatment
Product Details
| Gearing Arrangement | Planetary | Output Torque | 25000N.m | |
| Input Speed | 800r/min | Output Speed | 1500 | |
| Place of Origin | Shandong, China | Model Number | HLMC-30/55/70 | |
| Brand Name | Highland |
in wooden case
Product Description
Specifications
1.China Country Patent2.One year warranty
ncrete mixer reducer
planetary gear reducer
One . Features Overview :
Reducer models: Specifications HSG5 and HSG6 of two planetary gear ; specifications HSG7 of two planetary gears , spur gears first level
Direction of rotation: clockwise and counterclockwise
Purpose : drive rollers, support the weight of the moment and part of the drum
Two . Specific parameters :
Reducer Model : HSG5; HSG6; HSG7
Reduction ratio : 98.4 ; 111.8,121.7 ; 129.6
Efficiency reducer : 0.96 ; 0.96 ; 0.96
The maximum dynamic drum knife corner : ± 6 °; ± 6 °; ± 6 °
Reducer shaft slope : 15 °; 15 °; 15 °
Mounting angle of the drum : 8m ³ max14 °; 9-10m ³ max13.5 °; 12m ³ max12 °;
Weight (Kg): 233; 275; 304
Dose lubricants (L / min): 12; 16; 16
Types of lubricants : EP- gear lubricants
Note: No added EP gear oil additive will reduce the life of reducer 80%
Three . Technical parameters:
Maximum output torque (Nm): 51000; 61000; 71000
Allowable radial static load rollers (KN): 130; 180; 180
Intermittent radial roller allows dynamic load (KN): 265; 350; 350
Drum permissible axial static load (KN): 50; 65; 65
Intermittent drum permissible axial dynamic load (KN): 160; 230; 230
Performance output speed min-1 (rpm): 15; 14; 14
Maximum output speed min-1 (rpm): 18; 18; 18
