10G SFP Transceiver 20KM single mode BIDI Optical Transceiver

FOB Price

US$ 10 - 22 / Piece

10 Pieces(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China		Brand Name	Atongda
Model Number	ATD-10G-XXL

Transceiver 20KM single mode BIDI Optical Transceiver

1. Feat ure:

2. Application:

3. Absolute Maximum Ratings:

Parameter	Symbol	Minimum	Maximum	Units
Storage Temperature	Tst	-40	+85	℃
Supply Voltage	Vcc	0	+3.6	V
Operating Relative Humidity	RH	5	95	%

5. Optical Characteristics:

(Ambient Operating Temperature 0℃ to +70℃, Vcc =3.3 V)

Parameter	Symbol	Min.	Typ.	Max.	Units
Transmitter Section
Center Wavelength	lo	1260	1310	1360	nm
Spectral Width(RMS)	Dl	-	-	4	nm
Average Output Power	Po	-15	-	-3	dBm
Extinction Ratio	Er	12	-	18	dB
Rise/Fall Time(20%~80%)	Tr/Tf			0.26	ns
Total jitter	Tj			0.43	UI
Optical Eye Diagram	IEEE 802.3u and ANSI Fibre Channel Compatible
Receiver Section
Center Wavelength	lo	1260		1620	nm
Receiver Sensitivity	Rsen			-34	dBm
Receiver Overload	Rov	-3			dBm
Return Loss		12			dB
LOS Assert	LOSA	-45			dBm
LOS Dessert	LOSD			-34	dBm
LOS Hysteresis		0.5		5

6. Ordering information :

A-D0303-L3320C	Commercial	0~70℃
A-D0303-L3320C	Industrial	-40~85℃
