  Highland YST diesel fuel injection pump test bench/instrument/equipment

Application Range:

YST Series Hydraulic testing table are used for checking and proofreading the products that include hydraulic pump,motor and

valve,it also can conduct hydraulic system's breakdown diagnosis,these products are researched and produced by ourselves,so

we could combine conduct according to customers'needs.

Technical Parameters:

Flow Rate:500L/min

Pressure:35MPa

Power:150KW

Motive Force:Combined electric motor hydraulic drive,stepless speed regulation.

Hydraulic comprehensive test bench:

Hydraulic components test bench applicable to all kinds of general hydraulic components of the performance test, can satisfy

different user's testing requirements.

Hydraulic components test bench is divided into five varieties: hydraulic valve test rig, hydraulic pump test bench and hydraulic

motor Function test rig, hydraulic cylinder test rig and comprehensive test bench. This series of test bench has designed various

configuration, for example: proportional control system, digital display system, variable frequency speed regulation system and

computer measurement and control system etc, the user can select it according to your need.

1. National standards:GB/T8104,GB/T8105,GB/T8106,GB/T7936,GB/T 15622

2. Industry standards:JB/T8728,JB/T7039,JB/T7042,JB/T7044

3.Total power 75KW,90KW,110KW,132KW,160KW,315kw,350kw

4. Range of test presure 0~40MPa

5. Range of flow rate 0~500L/min

6. Range of rotational speed 0~3000r/min

7. Composition :Dynamic system, hydraulic control system, hydraulic oil filter       temperature control system and electric control

system, data  acquisition test system.

8.Applicable area:It apply to performance test of the hydraulic components that supported by a host in engineering machinery,

metallurgical, petroleum, machinery, aerospace, shipbuilding and other fields.
