Home > Products > 2. Evaporation/Concentration > Ethanol Distiller/ Alcohol Recovery Tower/ Alcohol Distiller
Ethanol Distiller/ Alcohol Recovery Tower/ Alcohol Distiller
- Shanghai
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
96% Alcohol Recovery Tower / Ethanol Rectifying Device
-
Top Quality Lastest Triple Effect Energy Saving Concentrator/Evaporator
-
Top Quality Lastest Triple Effect Energy Saving Concentrator/Evaporator Turkey
-
Top Quality Lastest Triple Effect Energy Saving Concentrator/Evaporator for Herbal Extract
-
China Industrial Triple Effect Juice Concentrator / Evaporator
-
Engineers Available Overseas Good Quality Rising Film Triple Effect Evaporator
Product Details
| Condition | New | Place of Origin | Shanghai, China | |
| Brand Name | Chengdong | Model Number | JH | |
| Processing Types | Alcohol | Voltage | 380V | |
| Power(W) | Accordingly | Dimension(L*W*H) | 2.3x0.7x7.3m | |
| Weight | Accordingly | Certification | ISO/GMP | |
| Warranty | 1 Year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Ethanol Distiller/ Alcohol recovery tower/ alcohol distiller
This device is used for the pharmaceutical, food, light industry, chemical and other industries to do dilute alcohol recovery, it will be helpful to reduce production costs, increase economic efficiency, the device can distill 30 degrees~50 degrees dilute alcohol to 90 degrees~95 degrees, finished alcohol has high request, can increase the reflux ratio, but the corresponding product yield decreased, the alcohol degrees of residue is less than 3 degrees, it is a good equipment specially for alcohol recovery.
This device adopts high efficiency stainless steel ripple packing, the parts which contact with alcohol, such as the tower body, condenser, buffer tank, cooling coil and etc. all adopt stainless steel to ensure the product is not contaminated, tower kettle uses removable U-type, easy to clean the heating outer wall and distilling inner wall, meet GMP standard.
| Type | JH200 | JH300 | JH400 | JH500 | JH600 | JH800 |
| Condensation area(m ²) | 8 | 16 | 25 | 30 | 50 | 70 |
| Cooling area (m ²) | 2 | 2 | 3 | 4 | 6 | 8 |
| Heat transfer (m ²) | 4 | 8 | 12 | 17 | 25 | 35 |
| Recovery ability(kg/h) | 45-50 | 80-120 | 120-180 | 250-300 | 350-420 | 550-650 |
| Equipment weight(kg) | 1100 | 1900 | 2300 | 3800 | 4500 | 6800 |
| Outer size(m) | 2.3x0.7x7.3 | 2.6x0.8x7.5 | 2.5x1x10 | 3x1.2x12 | 3.5x1.4x13 | 4.2x1.8x14 |
