Home > Products > power relay > Kontron Single/double Change-over Screw Mouting Double Contact 100A Power Relay
Kontron Single/double Change-over Screw Mouting Double Contact 100A Power Relay
US$ 6.5 - 8
/ Piece
100 Pieces(Min. Order)
- ShangHai
- Credit Card
You May Like
-
Kontron Single Pole Screw Mouting 150A Power Relay
-
Kontron Single/double Change-over Screw Mouting Double Contact 80A Power Relay
-
150 A Kontron Single Change-over Screw Mouting Double Contact Power Relay
-
Kontron Double Pole Flang-mouting 30A Heavy Duty Power Relay
-
Kontron Heavy Duty 40A Relay
-
KONTRON 3VU Overload Relay
Product Details
| Place of Origin | Shanghai, China | Brand Name | kontron | |
| Model Number | PFC-100F 1C 100A | Theory | Electromagnetic Relay | |
| Usage | General Purpose | Size | Other, 72X48X80 | |
| Protect Feature | Other, dust-proof cover | Contact Load | High Power |
Product Description
Power Power relay
| size | 72x48x80mm |
| contact form | 2C |
| contact rating | 80A 250VAC |
| contact resistance | ≤50mΩ |
| coil volt | DC:6,12,24,60,110,220 AC:6,12,24,60,110,220,380V |
| coil power | 3.6w 10.5VA |
| coil&contact strength | 2500VAC/1M |
| contact&contact strenth | 1500VAC/1M |
| insulation resistance | ≥500MΩ |
| electrical life | 50000 ops |
| mechanical life | 100000 ops |
| weight | 240 grams |
| terminal | screw |
| mouting | screw/flange |
| contact form | 1/2C |
