Flexible Shaft Coupling Price Flexible Universal Joint Pipe Flange Rubber Mechanical Flexible Coupling D25 L30

Specifications

Features:

1.Item Name: Flexible Coupling (Clamp Type)

2.Diameter: 25mm(0.984")

3.Length: 30mm(1.181")

4.Sleeve Material: Polyurethane

5.Body Material: Aluminum Alloy

6.Shaft Usage: 5mm/6mm/6.35mm/8mm/9.525mm/10mm/11mm/12mm

                        0.197"/0.236"/0.250"/0.315"/0.375"/0.394"/0.433"/0.472"

            (Please leave me a message about hole sizes for two sides)

7.Rated: In-phase Operate

Used to connect Servo Motors,Stepper Motors,Encoder,Screw Driving,Machine Plateform,Lifting Platforms, Stepping Servo System, Etc.

Advantage:

1.Compact design, simple structure,light weight,easy inspection and installation,low rotational inertia;

2.Fatigue resistance,and no rubber parts,wide temperature range of -50 to 200 degrees Celsius;

3.Could absorb vibration,compensate for radial,axial and angular misalignment;

4.Anti-oil,anti-corrosion and electrical insulation,maintenance-free;

5.Clockwise and counter-clockwise rotational characteristics,zero backlash;

OEM Service:

1.Customized design is available,OEM and ODM are welcomed;

2.Available with keyway or without keyway;

3.Material:Aluminum Alloy 6082 & 7003 & 7075,Stainless Steel 303 & 304 and Steel 45#;

4.Surface Processing:Polishing,Anodizing,Black Processing and Electroplating;

5.Packing: 1pc/PP bag,then pack with standard export or according to customers.
