DC Amp Meters/current Meter/moving Iron Meter

FOB Price

US$ 1 - 150 / Piece

100 Pieces(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

DC-A96 moving iron meter
Model:DC-A96 analog DC ammeter
Dispaly type:analog only
A.Founded in1980
B.CE,ROHS,SGS,UL,KEMA,VDE,

1panel meter with the accuracy class1.5
2panel meters with a high hit-resistance
3amp meters with a maximum electric isolation

Standards:
IEC51, IEC61010-1, VDE410, BS89, UL94, NE60051, DIN43780
Cases:	Temperature influence:
All cases at least dust and splash water-proof. All cases are made of strengthened self-extingushing PPO With a high hit-resistance and a maximum electric isolation	All instruments operate trouble-free at room temperature ranging from -25 to + 40. The Max. Voltage to earth Voltmeter-The upper range voltage (full scale deflention) Ammeter-The Voltage of the main power supply. The meter used shall be keep cleaning. The user shall be made aware that, if the meter is used in a manner not specified by the manufacturer, the protection provided by the meter may be impaired.
Accuracy class:
AC, DC Voltmeters and Ammeters comply with the accuracy class 1.5. The power meters comply with accuracy class 1.5. The frequency meters comply with accuracy class1.0. The maximum-demand meters comply with accuracy class 3.0. The power factor meters and synchroscope meter comply with accuracy class 2.5.
Insulation test:	Mounting angle:
The insulation test is carried out at a voltage of 2KV, 50Hz 1 min and applies for instruments with the full scale deflection up to 650V. Other standards comply with IEC61010-1.	The instruments are calibrated for vertical mounting, unless other positions such as horizontal or inclined at any specified angle to the horizon. can be provided upon request (in this case, specify angle of inclination, please) The accuracy class refers to the specified mounting angle only.

....
