Home > Products > Indicating Lamp & Push Button > AD22-22DS Led Indicator
AD22-22DS Led Indicator
- Shanghai/Ningbo
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Dixsen | |
| Model Number | AD22-22DS |
Product Description
AD22(LED)series of indicator is equally used LED shining chip as light source with long life, low consumption, small volume and light weight. AD22 indicators are produced by our factory enjoying by lots of clients. In order to fit in with top quality and aesthetic demand of user, we developAD22-22B, C, D, E, G, H, double color lamp, position indicator, shining buzzer and mini short indicator, as well as design shape of AD22-22G/22GS series button and it is possible to meet all kinds of international standard lampshade.
Main technical data:
(1)Voltage of working frequency: 205kV(AC valid calue), 1min.
(2)Insulated resistance≥ 2MΩ
(3)Voltage wave allowed by AC indicator± 20%
(4)Continual working life≥ 30000h
(5)Brightness≥ 60CD/m2
(6)Index of leakage CT1≥ 100
(7)Protection grade is IP40, and it is possible to be made to up to IP67
(8)Using frequency: AC50~60Hz
| Type | Voltage(V) | Case Qty.(Pcs) | Item code |
| AD22-22DS/R | 6, 12, 24, 36, 48, 110, 127, 220, 380 | 600 | 8022101 |
| AD22-22DS/G | 600 | 8022102 | |
| AD22-22DS/Y | 600 | 8022103 | |
| AD22-22DS/B | 600 | 8022104 | |
| AD22-22DS/W | 600 | 8022105 |
Dixsen was born in 1992, we are a professional manufacturer focuses on low voltage components like Current and voltage Transformers, Transformers, Meters, MCCBs, MCBs, AC Contactors, Fuse and Bases, Relays and sort of things. We locate in Wenzhou city, Zhejiang province, where is quite close to Shanghai and Ningbo port. A 15000 square meter area is divided into workshop zone and office zone, 430 employees are currently making their great efforts in that area for Dixsen brand.
Contact Us
- Zhejiang Dixsen Electrical Co., Ltd.
- Contact nameJane Zheng Chat Now
- Phone86-577-62865113
- AddressChang Jiang Road, Daqiao Industrial Zone, Wenzhou, Zhejiang
