Belt-conveyor idler roller---vertical idler roller
- 10000 Piece / Pieces per Month
- Tianjin Xingang Port
- T/T
You May Like
Product Details
Place of Origin | Hebei, China | Brand Name | HXT | |
Model Number | 89*305 |
Product Description
The International Markets:Southeast Asian/ Eastern Europe /Western Europe /North American /South American /Africa /Oceania /Russian
Contract Manufacturing : OEM Service Offered Design Service Offered Buyer Label Offered
Detailed Product Description
Vertical idlers:
It is also called side idlers,used in belt conveyor with sides. Stampiron bearing seat Tripe labyrinth seals low torque requirements
Size sheet :
Diameter mm | Length mm | Bearings No. |
89 | 180,190,200,235,240,250,275,280,305,215,350,375,380,455,465,600,750,950,1150 | 204 |
108 | 190,200,240,250,305,315,360,375,380,455,465,525,530,600,700,750,790,800,950,1150,1400,1600 | 204 205 305 306 |
133 | 305,375,380,455,465,525,530,600,670,700,750,790,800,900,950,1000,1100,1150,1400,1600,1800,2000,2200 | 205 305 306 |
159 | 375,380,455,465,525,530,600,700,750,790,800,900,1000,1050,1100,1120,1150,1250,1400,1500,1600,1700,1800,2000,2200,2500,2800,3000,3150, | 305 306 308 |
193.7 | 2200,2500,2800,3000,3150,3350 | 308 310 |
217 | 600,640,1050,1120,1600,1700,3150,3350, 308 310 |
(or as drawing or samples)
Technical data:
l Tube(pipe) material :carbon steel pipe
l Tube (pipe) diameter :89-217
l Tube wall thickness : more than 5 mm
l Tube length :180-3350 mm
l Shaft extemal length :10-40 mm on each side or as drawing
l Distance between each idler frames ranges from 900 mm to 1500 mm roller
l Distance are generally fixed at 1 meter to 15 meter gap
l Belt width ranges from 300 mm to 2000 mm
l Idler bracket is fabricated from mild steel
Advantages:
- Life span≥30000hour
- Light and rigid frame construction
- Sealing arrangement consist of a double seal
- Additional water proofing neoprene contact lip seal
- Low friction coefficient, waterproof, effective sealing system
- High accurate steel pipes ensure the rollers with low vibration and noise
- Multi-labyrinth seals achieve waterproof and dust proof
- Adopting good bearing make sure the lifetime, stable running and good quality
- Excellent lubricating property
We are a company specilizing in making conveyor idler rollers,conveyors,idler roller fitting (in different size).If you have interest and want more details,please contact with me!
