Belt-conveyor idler roller----trough idler roller

The International Markets:Southeast Asian/ Eastern Europe /Western Europe /North American /South American /Africa /Oceania /Russian

Contract Manufacturing : OEM Service Offered Design Service Offered Buyer Label Offered

Detailed Product Description

Trough idlers (conveyor roller)

It is the part used to support belt and material loaded on the belt conveyor .There are two types accordance to its shape :standard type and pitch type .The pitch type can be fit on all the line , and it have belt adjust function.

Size sheet :

(or as drawing or samples)

Technical data:

l  Tube(pipe) material :carbon steel pipe

l  Tube (pipe) diameter :89-217

l  Tube wall thickness : more than 5 mm

l  Tube length :180-3350 mm

l  Shaft extemal length :10-40 mm on each side or as drawing

l  Distance between each idler frames ranges from 900 mm to 1500 mm roller

l  Distance are generally fixed at 1 meter to 15 meter gap

l  Belt width ranges from 300 mm to 2000 mm

l  Idler bracket is fabricated from mild steel

Advantages:

• Life span≥30000hour
• Light and rigid frame construction
• Sealing arrangement consist of a double seal
• Additional water proofing neoprene contact lip seal
• Low friction coefficient, waterproof, effective sealing system
• High accurate steel pipes ensure the rollers with low vibration and noise
• Multi-labyrinth seals achieve waterproof and dust proof
• Adopting good bearing make sure the lifetime, stable running and good quality
• Excellent lubricating property

We are a company specilizing in making conveyor idler rollers,conveyors,idler roller fitting (in different size).If you have interest and want more details,please contact with me!
