Home > Products > Common Rail Fuel Injector Test Bench > Test Oil Quantity,HY-CRI200A Common Rail Tester

Test Oil Quantity,HY-CRI200A Common Rail Tester

FOB Price

Negotiable / Set

1 Set(Min. Order)

Port Qingdao
Payment TermsT/T Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Type	Engine Analyzer	Voltage	380V
Power	2.2kw	Certification	CE, ISO9001:2008
Place of Origin	Shandong, China	Brand Name	Haiyu
Model Number	HY-CRI200A

Packaging Details

wood package fit for delivery

Product Description

Specifications

1.HY-CRI200A common rail injector test bench
2BOSCH rail pipe and pump
3Cast iron operation platform
wood package

HY-CRI200A high pressure common rail injector test bench

provide operating video

Introduction:

HY-CRI200A type high pressure common rail injector test bench.400kinds of standard statistics of common rail injector are built in. with high accuracy flow test detection equipment. It can automatically test the oil injection and oil return under the circumstance of sealing, full load, idle operation, preinjection. The test bench with high compacted structure can transmission smoothly, is reliable and operated simply, small size for easy mobility.

Main function:

1. Variable frequently drive pump serves the common rail BOSCH CP3.3 and the maximum pressure is 200Mpa. Automatic closed-loop control rail press accuracy displayed is± 0.1Mpa.
2. Adjustable inject frequency and time.
3. Built-in standard database of common rail injection pump, data can be update and added freely by users.
4. The standard database contains the waveform control data of all types of injection pump, and it can output the standard waveform control signal to the injection pump.
5. It can test BOSCH, DENSO, DEPHI and SIEMNES.
6. Industrial computer motherboard and embedded operating system Windows XP. It is screen displays basic status such as: the rail pressure, temperature ,host operation, speed, heating, cooling, also has some windows for fuel injection pump test, common rail test, fuel measurement, parameter setting, injection waveform, problem analysis and data reports.
7. Touch screen operation, easy to learn and use

8. Oil injection and oil return are automatically detected and clearly displayed on the large screen

9. Test data reports can be generated, stored and print (can be choose)

10. Testing the sealing of the common rail injection pump

11. Testing the condition of idle speed

12. Testing the condition of pre-injection

13. Testing the condition of the atomization quality

14. Function of high pressure cleaning of the injector

Parameters:

Name and Model	System	Specification Details	Remarks
HY-CRI200A High Pressure Common Rail Injector Test Bench	Main Engine System	2. The main frame is aviation aluminum structure and cast iron operating platform. 3. Its control type is automatically computer control and display by screen. 4. The accuracy of weighing oil digital readout (weighing transducer) is 0.1ml. 5. Its revolving speed range is 0~1500r/min (adjustable) (digital readout).	Furniture Included
	Oil Circuit System	1. The high pressure pump is BOSCH, CP3.3, max 200Mpa. 2. Rail pipe is BOSCH. 3. The rail pipe is controlled by automatically closed cycle, and pressure display (accuracy±0.1Mpa) with overpressure protection. 4. Oil temperature (adjustable) is controlled automatically heated by heating pipe and radiated though radiator. 5. Its filtering type is secondary filter.
	Electrical equipment	1. It has built-in electrical box and convert box. 2. Short-circuit protection.
	Data base	It has more than 600kinds of standard build-in data, which can be upgraded.
	Testing fuel injector	1. It can test 1 fuel injector every time. 2. It can test 6 fuel injectors at most in the same time (Price is extra). 3. The types it can test are BOSCH, DENSO, DELPHI, and SIEMENS.
	Overall dimension	Length: 1000mm, Width: 850mm, Height: 1430mm
	Weight	Net weigh: 400kg.
