glass block

Specifications

Glass block is made by glass sand,soda ash,quartz power and other silicate which melted in high temperature.It has no poison,no peculiar smell and takes no encroachment to human’s body.It is green environmental protectal production in reality as well as in name.Glass block is a new building decorative production.

The glass block has characteristic of pervious to light but  untransparent,soud insulation,high thermal resistance,low conduction of heat,high intensity,able to endure corrosion,heat preservation,moist insulation,etc.The designs are beautiful and luxurious.It is easy and convenient to build  and widely on wall decorated in the room or outside.

Glas block introduction

1.The big area wall of glass block not only has the stability but also hasthe stability of window: you can look the outside scenery and sunlight, and themoving note.

2.Using on the bit building top, glass block not only can ensure thesecurity , but also brighten the whole building.

3.The unique curved partition wall of glass block, not only has theexcellent ability of heat insulation and heat preservation. But also combineprivacy and harmony together. It can make you enjoy the relaxed lifecompletely.

4.Ability of controlling light can avoid the gloomy and cold feeling whichis brought by caliginous space. Glass block can create a vernal and colorfulhome environment; also

specification

Glass block  catalogue

Glass block performance

 1. Environmental Friendliness

Belonging to sodalime silicate glass system, glass tile, a transparent material, is made by melting silicate inorganic mineral substance materials such as quartz sand, soda ash (Na2CO3) and limestone at high temperature, being a veritable eco-friendly product.

2. Heat-shielding Performance

Due to the diffuse scattering of hollow glass tile and internal negative pressure cavity, a room can get enough light rays and the interior temperature does not rise under strong solar radiation in summer. In winter, the difference between indoor temperature and outdoor temperature can reach 40 DEG C and the air humidity is not influenced because of low thermal coefficient and great loss of blocked heat in the negative pressure cavity. If the glass tile is applied to a building, the room gets cool in summer and is away from torridness, and warms the room, does not cause dryness and saves energy in winter.

3. Sound Insulation Performance

Thanks to sealing negative gas in the hollow glass tile, the tile has high sound insulation property.

4. Light-transmitting and Non-perspective Performance

The light-transmission coefficient of white hollow glass tile is 75%-85%, which is similar to that of the general double-layered hollow glass. There are various decorative patterns on the surface of the glass tile, so the tile is non-perspective, indoor imperceptibility is realized, light rays are scattered around the room, discomfort caused by direct solar radiation is solved and the indoor luminous environment is improved.

5. Fireproof Performance

The fireproof level of hollow glass tile is GB class A. According to Japanese law, it is recognized that single-layer wall has the same performance as the second kind fire door and double-layer wall has one-hour fireproof performance.

6. High Compression Resistance and Shock Resistance
The hollow glass tile has high compression resistance and shock resistance, so that the dead weight of the hollow glass tile can be ignored even in design and construction of very high glass tile wall.

7. Atomization Resistance
The hollow glass tile has outstanding performance in resisting pulverization. For example, the surface of the glass tile does not atomize or form dew when the indoor temperature is 20°C, the humidity is 60% and the outdoor temperature is 2°C below zero, so that the erosion of atomized vapor to the frame is prevented.

The following information is based on a typical 190*190*80mm clear glass block
Composition : Silica-sand, soda ash, calcium.
Fusion is obtained at approximately 1550OC.
Light Transmission
Clear 190x190x80 = 80%
Coloured 190x190x80 = 60%
Thermal Transmission
Average value = 2.9 W/m² °C : Single Wall.
Impact Strength
12.0 N/mm - Tested using 50kg sand bag and steel ball bearings.
Sound Transmissions
Rw = 42dB depending on frequency.

Applications

1.External use of windows, doors, shopfrontsin offices, houses, shops etc.

2.Interior glass screens, partitions,balustrades etc.

3.Shop display windows, showcases, displayshelves etc.

4.Furniture, table-tops, picture frames etc.
