EM1X Embeded 2 Inch Thermal Printer Module

EM1X embeded 2 inch  Thermal Printer module

Overview:

2-inch thermal printer module

This thermal printer module, with tear bar for paper cutting, has plug and play capability, which greatly reduces the time-to-market. Characterized by high speed, little noise, and high reliability, it is widely used in measuring devices, medical equipments, etc.

Application:
1. Protable printers and terminals
2. Hand held ternimals
3. Measuring instruments and analyzers
4. Data terminal devices
5. Medical equipments
6. Taximeters

Features:

Unique Functions:
1. World's smallest 57mm*Φ50 thermal printer module
2. Used as panel printer when fixed on an iron plate, and used as an embedded printer when embedded in other devices.
3. With software command to enter standby mode, and ultra low standby current (6.0mA), which is very applicable to the devices with battery.
4. To control the number of dots and the interval of heating by the software command, and allocate the peak current
5. SAM connector space in side each is applicable for SD or SAM card(customizable).

Functions:
1. Support Windows/Linux driver
2. High printing endurance up to 100km(by using F230AA Mitsubishi paper, DJ03 or equivalent thermal paper)
3. High printing speed up to 80mm/s (at 8.5V)

Specification:

  EM1X embeded 2 inch  Thermal Printer module
