Product Details
| Condition | New | Type | Hot Press Machine | |
| Place of Origin | Shandong, China | Brand Name | RLK | |
| Model Number | RLK21-4'*8'/40-15 | Voltage | 380V | |
| Power(W) | 14.1kw | Dimension(L*W*H) | 3560*1370*4240mm | |
| Weight | 32000kg | Certification | CE ISO9001 | |
| Warranty | 3 years | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
particle board hot press machine hot press machine hot press laminator machine vacuum hot press machine
Model | RLK21-4'*8'/40-15 |
Frame style | Combination frame |
Quantity and Diameter of Cylinder | 2 units Φ320mm |
Nominal Pressure | 400Tons |
Quantity of layers | 15 layers |
Separation between layers | 70mm |
Stroke of Cylinder | 1050mm |
No-load closing time | About 15s |
Hydraulic system control method | Manually/Automatic controlled |
Hydraulic system pressure | 25MPa |
Main motor | 11KW |
Pressurized motor | 7.5KW |
Main pump | Shanghai Aviation 250 pump |
Pressurized pump | 10ml/rev plunger pump |
Heating platen(working table size) | 2700*1370*42mm |
Heating Meduim in the heating platen | steam or heat transfer oils |
main frame steel plate thickness | 35,22,12mm |
Upper, Bottom crossbeam | 900,800,400mm |
Movable crossbeam | 2700*1370*400mm |
Dimensions of Main frame | 3560*1370*4240mm |
Weight | 32000KG |
Production Capacity | about 30 sheets of plywood in one hour |
Upper&Bottom Crossbeam | 800mm 900mm |
Welcome your inquiry and visit about particle board hot press machine hot press machine hot press laminator machine vacuum hot press machine
