ESATA 7P+USB 4P Male 90 Degree DIP Connector

FOB Price

US$ 0.02 - 1 / Piece

1000 Pieces(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

ESATA 7P+USB 4P Male 90 Degree DIP Connector
1.7P+USB
2.DIP Type,with fork
3.Color: black
4.RoHs,CE,UL

ESATA 7P+USB 4P Male 90 Degree DIP Connector

Detailed Product Description

Material:	1. Contact: brass C2680R EH, T=0.25mm
	2. Color: black
	3. Housing: LCP 30% G/F UL 94V-0
Contact:	1. 5u"/3u"/ gold/ tine plating on contact area 100u" min
	2. tin-lead plating on solder tails 50u"min
	3. nickel underplating over all
Electrical:	1. Current Rating: 1.5A per pin min
	2. Insulation Resistance: 1000MΩ DHM Min
	3. Dielectric Withstanding voltage: 500V AC
	4. Contact Resistance: 30m DHM max
Environmental:	1. Storage Temperature: -10°c ~ 40°c relative humidity:<80%
Environmental:	2. Operation Temperature: -40°c ~ +70°c

Advantage:

All kinds of products passed ROHS.
Our Factory has passed the ISO9001:2000 certification and ISO1400 Certification
Rich experience in manufacturing
We are glad to make samples according to your drawings and specifications.
Our products are extensively used in electronic and othe industries
Well-equipped testing facilities and strong technical force
Please contact us so we can offer you the best quality,competitive price and timely delivery.
