110kw lovol water power used diesel generators with CE approved

Specifications

 110kw lovol water power used diesel generators with CE approved

Engine model: 1003G, 1003TG, 1004G, 1004TG, 1006TG1A, 1006TG2A, 1006TAG1A, 1006TAG

Performance Feature
- Engine and alternator shall be mounted on a same frame steel skid.
- Built-in damper for anti-vibration.
- Small size, low weight, easy to operating, installation and maintenance.
- World most famous brand diesel engine.
- World famous brand AC alternator: Stamford, Marathon, Leroy Somer, MVC.
- Advanced and reliable control module: Key start, Auto start, Remote control by PC with RS232/485
- Full range protect function and alarm shutdown feature.

Protection Standard: IP21-IP23
Model of connection: 3 phase 4 lines
Insulation Grade: H
Frequency Drop(%): ≤ 0.5
Transient state frequency deviation(%): (advertised power) +10-7
Frequency Recovery Time(S): ≤ 3
Voltage Recovery Time(S): ≤ 4
Waveform Distortion(%): ≤ 5

Alternator for option

Alternator Feature
- Brush-less, 4 poles, rotation magnet.
- IP21-23(NEMA1) enclosure is standard for all industrial alternators.
- The insulation system is Class H
- Simple installation and maintenance, with easy access to terminals, rotating diodes and coupling bolts.
- Wide range of flange adaptors and single bearing disc coupling.
- Standard 2/3 pitch windings avoid excessive neutral currents
- AVR auto voltage regulator, auto exciter, auto adjustment

Standard Accessory
Common steel base frame, Circuit breaker, Damper, Exhaust silencer, Flexible pipe, Battery and connecting wires, Operation manual and document.

Optional Accessory

Engine coolant and oil heater, Alternator space heater, Cooling for heat exchanger, Control system with RS232/485 communication interface, Battery charger by main supply, Fuel-water separator, Daily fuel tank, ATS & paralleling system, Soundproof Canopy and Moving Trailer.

Lovol generator 20kw to 110kw data

Controller
