Automatic high-speed roll feeding machine

FOB Price

Negotiable / Set

2 Sets(Min.Order)

Supply Ability 20 Set / Sets per Month
Port Shenzhen Shekou

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China		Brand Name	YOUYI
Model Number	RFSeries		After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Automatic high-speed roll feeding machine

Product Description

Features

1.Suit for muti-stage production.

2.Simple structure, cost saving, low failure rate and easy to maintain.

3.Feeding accuracy: 0.05mm in common. It can be within 0.01 when use a guide pin.

Specifications

Model	Material width	Material length	Material thickness	press power	weight	pass line
RF105NS	100 mm	50 mm	0-1.6 mm	5-20T	64KG	50-110
RF205NS	200 mm	50 mm	0-1.6 mm	20T	87KG	50-110
RF255NS	250 mm	50 mm	0-1.6 mm	20T	95KG	50-110
RF305NS	300 mm	50 mm	0-1.6 mm	40T	103KG	50-110
RF355NS	350 mm	50 mm	0-1.6 mm	40T	111KG	50-110
RF405NS	400 mm	50 mm	0-1.6 mm	60T	121KG	50-110
RF455NS	450 mm	50 mm	0-1.6 mm	80T	131KG	50-110
RF505NS	500 mm	50 mm	0-1.6 mm	80T	141KG	50-110
RF555NS	550 mm	50 mm	0-1.6 mm	110T	151KG	50-110
RF605NS	600 mm	50 mm	0-1.6 mm	110T	161KG	50-110
RF158NS	150 mm	80 mm	0-1.6 mm	10-60T	76KG	70-150
RF208NS	200 mm	80 mm	0-1.6 mm	20-60T	84KG	70-150
RF1510NS	150 mm	100 mm	0-3.5 mm	40-60T	142KG	70-150
RF2010NS	200 mm	100 mm	0-3.5 mm	40-80T	155KG	70-150
RF3010NS	300 mm	100 mm	0-3.5 mm	60-160T	180KG	70-150
RF4010NS	400 mm	100 mm	0-3.5 mm	80-260T	200KG	70-150
RF5010NS	500 mm	100 mm	0-3.5 mm	110-260T	220KG	70-150
RF6010NS	600 mm	100 mm	0-3.5 mm	160-260T	240KG	70-150
RF7010NS	700 mm	100 mm	0-3.5 mm	160-260T	260KG	70-150
RF1515NS	150 mm	150 mm	0-3.5 mm	40-60T	143KG	70-150
RF2015NS	200 mm	150 mm	0-3.5 mm	40-80T	156KG	70-150
RF3015NS	300 mm	150 mm	0-3.5 mm	60-160T	181KG	70-150
RF4015NS	400 mm	150 mm	0-3.5 mm	80-260T	201KG	70-150
RF5015NS	500 mm	150 mm	0-3.5 mm	110-260T	221KG	70-150
RF6015NS	600 mm	150 mm	0-3.5 mm	160-260T	241KG	70-150
RF7015NS	700 mm	150 mm	0-3.5 mm	160-260T	261KG	70-150
RF1520NS	150 mm	200 mm	0-3.5 mm	40-60T	146KG	70-150
RF2020NS	200 mm	200 mm	0-3.5 mm	40-80T	159KG	70-150
RF3020NS	300 mm	200 mm	0-3.5 mm	60-160T	184KG	70-150
RF4020NS	400 mm	200 mm	0-3.5 mm	80-260T	204KG	70-150
RF5020NS	500 mm	200 mm	0-3.5 mm	110-260T	224KG	70-150
RF6020NS	600 mm	200 mm	0-3.5 mm	160-260T	244KG	70-150
RF7020NS	700 mm	200 mm	0-3.5 mm	160-260T	264KG	70-150
