500 m Water Well Drilling Rig for Sale.
- Qingdao port
 - Credit Card PayPal

You May Like
-


China Water Well Drilling Rig With LGX-W180.
 -


Water Well Drilling Rig Machine With Drilling Depth 300 m
 -


Drilling Machine is Used in Water Well Drilling Rig With 400 m.
 -


Drilling Hole Machine With Depth Hole 500 m Drilling Machine for Water Well.
 -


Drilling Water Well Machine With Small Model for Water Well.
 -


High Performance Drilling Rig Machine With Water Well 300 m.

Product Details
| Condition | New | Type | Rotary Drilling Rig | |
| Power Type | Diesel | Place of Origin | Shandong, China | |
| Brand Name | Legos | Model Number | LGX-W500 | |
| Usage | Water Well | Voltage | 220V/380V | |
| Power(W) | 132KW | Dimension(L*W*H) | 8085x2250x3200mm | |
| Weight | 12.5T | Certification | ISO,CQC,CE. | |
| Warranty | One Year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
QIingdao ligaoxin Machinery co.,Ltd
We can offer the various of drilling rig ,Including for surface DTH drilling rig ,Separate drilling rig, full hydraulic drilling rig, and top hammer drilling rig,integrated hydraulic drilling rig and undergroud drilling rig, crew air compressor.drill bit and drill steel, and so on.If you need ,You can call me or send to me your email.
Main advantage
1.Proved component quality, widely applicable in different well drilling.
2.Hoist can lift drill steel and auxiliary up to 200kN that greatly reduce the workload of the operator.
3.Equipped with two speed tramming motor to adapt to all road conditions.
4.Feeding and lifting can be switched to fast or slow mode to increase drilling efficiency. Two rotation speed adapts different hole size and geological conditions
Specifications
| Style | water drilling rig |
| Model | LGX-W500 |
| Aperture | 130-350mm |
| Drilling depth | 500m |
| Rotation torque | 4250-8500N.m |
| Rotary speed | 90-180Rpm |
| Thrust Capacity | 60KN |
| Feed stroke | 5300mm |
| Lifting capacity | 200KN |
| Travel speed | 3km/h |
| Grade ability | 25° |
| Rising height from ground | 300mm |
| Working pressure | 1.45-3.5mpa |
| Air consumption | >25m³/min |
| Engine power | 132KW |
| Dimension | 8085x2250x3200mm |
| Gross weight | 12.5T |
Application
Display with LGX-W500 model

Pictures with customer
Certification
Our per machine is passed the factory's test,So that make sure production quality. We product is according to international standard.Such as ISO,CE,CQC certification .we can give the best machine with each customer.
Field Cast
About Us
Qingdao Ligaoxin Machinery Co., Ltd. is a sales and aftersales service as one of the main scientific and technological company, has long been committed to the air compressor industry and the development of drilling industry. And with many famous brand enterprises to establish a good and stable partnership, forming a cooperative mechanism with strong vitality, interdependence and common development.
The company believes in: "quality first, customer first" principle, with a strong network of cooperation, leading technology, rich experience in the industry and excellent product quality, affordable price, professional standards of aftersales service and modern marketing management concept, rapid development and expansion, the product has been widely recognized and approved.
Let users enjoy the quality and reliable, cost-
effective, service perfect product is our goal, we created adynamic and cohesive marketing design and maintenance team, to provide customers with timely, quality and efficient services, to help customers improve competitive advantage, bringrationalization and maximize the investment benefits, achieve a wonderful win- win, and for the "Made in China" to contribute our strength.
Corporate culture: innovation, cooperation, win-win.
Business philosophy: in good faith principle, industry and technology oriented , to win through good service.
