Operate the Mortar Grouting Pump
- Shanghai Qingdao Tianjin
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Condition | New | Power Type | Electric | |
| Place of Origin | Henan, China | Brand Name | SINCOLA | |
| Model Number | SG50-40 | Power(W) | 5.5 kW(Electric)/10hp(Diesel) | |
| Weight | 300 kg | Dimension(L*W*H) | 1610*1024*900 mm | |
| Certification | ISO9001;2008 | Warranty | 1year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
the international stanard packing
Product Description
Specifications
mortar grouting pumpElectric Mortar Pump for wet-mixed mortar
Durable quality and best after-sale service
Top SeLL
Diesel mortar grouting pump working
Introduction:
how diesel pump working, you can see the following description. the machine SG50-40 diesel electric pump with single cylinder and double acting is widely used for its convenient maintenance, high working pressure and high efficiency, working reliability, compact structure etc. it can be used not only for grouting cement mortar and sand mortar, combined with accessories such as compressor and spraying gun, it is also ideal equipment applied in spraying. It is widely used for grouting in mine gallery, rail and road tunnel, hydropower construction, slope consolidation, underground engineering, subway and civil engineering etc.
Feature:
- Single piston single acting
- Switch by ball valve
- Mechanical transmission, lower failure rate
- Integrate pump head and hopper; prevent eduction and deposition together with the paddle agitating
- Compact structure, convenient for maintaining
Technical data:
Item | SG50-40 |
Cylinder Dia | φ90 mm |
Output | 50 L/min |
Pressure | 4 Mpa(40bar, 580psi) |
Piston stroke | 85 mm |
Piston Speed | 95 /min |
Inlet diameter | 75 mm |
Outlet diameter | 50 mm |
Max.Aggregate.size | 5 mm |
Cement : Sand | ≥1:3 |
Dimensions | 1610×1024×900 mm |
Weight | 300 kg |
Power unit | 5.5 kW(Electric)/10hp(Diesel) |
Note: Single or Double Passageway.Skid or Tyre | |
Zhengzhou Sincola Machinery Co.,Ltd is a stated- designated manufacturer and exporter of road and building construction machineries. We are the one of the big manufacturer and supplierin China .
Our products are Shotcrete machinery and Concrete Pump,Plaster Machine,Mortar Pump,Spraying Machine,Industrial Hose Pume,Grouting Pump,Automatic rendering machine. Also we are the manufactur,supplier and exporter of semi-automatic and full-automatic dry motar mixing plants.large and medium size of concrete mixing plants.
Our company engaged an international expert guidance, the study has been made a number of patents.Our technical experts from the United States, Germany, Italy and other multi-national team of experts.
Our products are well known to international market such as Russia, UzbekistanRussia,Uzbekistan,Cyprus,Algeria,Cameroon,Macedonia,Malaysia,Austrialia,Yemen,Oman etc.
Our products have widely been applying in construction, railway and super highway engineering, underground engineering, tunneling, mining operation,hydropower projects and slope stabilization.
